B265LM Bronze Chirp Thru-Hull Transducer 1kW with Fairing Block - Mix & Match Cable Needed

The B265LM Chirp-ready transducer is the perfect mid-range to deep performing transducer in the Airmar line. Covering a huge bandwidth, the frequency performance on many species delivers crisp, clear target separation. This 1 kW powerhouse transducer delivers extreme target detail, bottom discrimination, and bait and game fish separation at all depths. The included High-Performance Fairing will give you broadband performance at speeds over 30 knots (34 MPH). We will leave it up to you to discover the rest of the secrets that can be unlocked with tunable, Chirp Broadband Transducer Technology.

LM Model - Low Frequency 42-65 kHz/Medium Frequency 85-135 kHz

Features:

• Depth & fast-response water-temperature sensor
• 1kW power for excellent deep to mid-depth performance
• Low frequency: 42 kHz to 65 kHz

• 25° to 16° beamwidth (port-starboard)
• Maximum depth 3000' (914 m)

• Medium frequency: 85 kHz to 135 kHz

• 16° to 11° beamwidth
• Maximum depth 1500' (457M)

• 73 kHz of total bandwidth from one transducer
• Covers popular fishing frequencies of 50, 88, and 107 kHz plus everything else in the bandwidths
• Bronze transducer housing with High-Performance Fairing for improved high speed performance
• Recommended boat size: 8 m (25') and above
• Hull Type: Fiberglass or wood
• Models also available in Transom Mount (TM265LM), Pocket Mount (PM265LM), Cavity Mount (CM265LM), In-Hull (M265LM)
• Exclusive Xducer ID® technology

Specifications:

• Hull Deadrise: Up to 20° with fairing
• Acoustic Window: Urethane
• Weight: 7.3 kg (16 lb)

Specifications:

• Mounting Style: Thru-Hull
• Chirp: Low/Medium
• Box Dimensions: 5"H x 12"W x 16"L WT: 23 lbs
• UPC: 801769001600

Furuno 556TID-HDD SS260 Stainless Steel Thru-Hull Transducer w/Temp and Fairing Block - 10 Pin [556TID-HDD]

Ships Direct From Manufacturer

556TID-HDD SS260 Stainless Steel Thru-Hull Transducer w/Temp and Fairing Block - 10 Pin

The SS260 is our best performing, stainless-steel, thru-hull stem for 1 kW echosounders. Its construction utilizes separate 50 kHz and 200 kHz elements for unparalleled deep-water performance and unmatched bottom and water-column detail. The SS260’s narrow beam gives crisp image detail especially suited for fishing shelves, intricate bottom structures, and wrecks.

Standard Features

• 1,000 Watts Power
• 50/200 kHz with Diplexer
• 20/6 degree Beam Angles
• Stainless Steel Thru-Hull with Temperature
• 10-Pin Connector
• High Speed Fairing Block included

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

• Imaging: Standard
• Temperature: Yes
• Speed Included: No
• Pins: 10
• Mounting Style: Thru-Hull
• Chirp: No
• Box Dimensions: 7"H x 18"W x 26"L WT: 22.15 lbs
• UPC: 611679310606

Brochure (pdf)

Raymarine B175H-W 1KW Bronze Thru Hull 12 Tilted Element [A80320]

Ships Direct From Manufacturer

B175H-W 1KW Bronze Thru Hull 12° Tilted Element

Features:

• Installation: Thru Hull
• Material: Urethane
• Power (RMS): 1kW
• Max Depth(ft): 800
• Frequency (KHz): 150-250
• Records: Depth and Temperature
• Approved Hull Material: Fiberglass/Wood
• Cable Length (ft/M): 6ft/2M
• Supported deadrise: 8-15° Deadrise

Additional Notes: All wide beam products come with a 2M pigtail off the transducer. Requires a Transducer Extension cable for a Complete Transducer Installation. 10M Extension Cable part number A80327 and A80328 Single B75/B175 operation cable.

Specifications:

• Speed Included: No
• Temperature: Yes
• Mounting Style: Thru-Hull
• Imaging: Standard
• Chirp: High Wide
• Cable Length (Feet): 6'
• Box Dimensions: 8"H x 10"W x 12"L WT: 9.75 lbs
• UPC: 723193796269

Raymarine M265LH 1kW Urethane In-Hull Transducer w/In-Hull Mounting Kit [A80012]

Ships Direct From Manufacturer

M265LH 1kW Urethane In-Hull Transducer with In-Hull Mounting Kit

The M265 is an outstanding in-hull option with 8 internal ceramics and up to 117kHz of total CHIRP range. The in-hull installation eliminates the need to drill any holes in the hull, while accommodating a large range of deadrise angles. The medium-frequency benefits include the ability to identify targets deeper than the high-frequency with benefit of a wider beam angle. The high frequency provides excellent shallow water resolution.

Specifications:

• Temperature: No
• Speed Included: No
• Mounting Style: In-Hull
• Imaging: Standard
• Chirp: Low/High
• Box Dimensions: 8"H x 10"W x 11"L WT: 11.9 lbs
• UPC: 723193706244

Garmin Panoptix LVS32-TH Transducer Thru-Hull Mount [010-12928-01]

Ships Direct From Manufacturer

Panoptix™ LVS32-TH Transducer Thru-Hull Mount

This transducer is part of the Panoptix LiveScope System and requires the GLS 10 sonar black box to function. You get both LiveScope™ Down and LiveScope™ Forward modes in one transducer. It’s easy to adjust the transducer mode to fit your fishing techniques; use LiveScope Forward to see remarkably clear images of structure and swimming fish around your boat, and use LiveScope Down to see directly below your boat. The view automatically updates on your compatible Garmin chartplotter. Attitude Heading Reference System (AHRS) stabilization keeps your sonar view steady, even in rough conditions.

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Mounting Style: Thru-Hull
• Box Dimensions: 5"H x 10"W x 15"L WT: 6.7 lbs
• UPC: 753759230746

Furuno B785M Bronze Thru-Hull Chirp Transducer w/High Speed Fairing Block [B785M]

B785M Bronze Thru-Hull Chirp Transducer with High Speed Fairing Block

Features:

• Frequency: Chirp 80 - 130 kHz
• Power Rating: 600 Watts
• Connector: 10 Pin
• Fairing Block: High Speed Fairing Block Included

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

B175L 20° CHIRP Bronze Thru-Hull 1kW - Needs Mix & Match Cable

Features:

• Category: Chirp
• Power: 1kW
• Function: Depth,Temperature
• Frequency: 40-60 kHz
• Mount Style: Thru-Hull,Flush,Tilted
• Housing Material: Bronze

Specifications:

• Chirp: Low
• Mounting Style: Thru-Hull
• Box Dimensions: 8"H x 10"W x 12"L WT: 11.4 lbs
• UPC: 801769001860

R509C-LH CHIRP Transducer

Features:

• Fishing Profile: Commercial and recreational inshore and offshore fishing (deep-water canyon and sea-mount tracking)
• 25-Internal, Broadband Ceramic Elements
• Broadband / CHIRP / Spread Spectrum
• Operating frequencies:
  • Low—Chirps from 28 kHz to 60 kHz
  • High—Chirps from 130 kHz to 210 kHz
• Beamwidth (Adjustable):
  • Low—23° to 9°
  • High—8° to 4°
• 10 m (33’) cable, no connector
• Fast-response water-temperature sensor
• Boat size: 12 m (40’) and above
• Hull Type: Fiberglass, wood, or metal
• Exclusive Transducer ID®

Specifications:

• Chirp: Low/High
• Box Dimensions: 13"H x 17"W x 27"L WT: 55.35 lbs
• UPC: 801769001440
