PM111 LHW CHIRP 2kW Wide-Beam Chirp-Ready Pocket/Keel Mount - No Connector

Get more coverage under your boat with Airmar’s unique wide-beam, high-frequency, Chirp-ready transducer. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high-frequency band results in superior resolution. The constantly wide beam provides twice the coverage and excellent fish arches on the display compared to most high-frequency, narrow-beam transducer options.

The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essentially down to 152 m (500').

The low-frequency band and 2 kW of power also support great deep-water performance. Get the best of both worlds with Airmar’s dual-frequency, Chirp-ready transducer with wide-beam coverage.

Features:

• The depth and fast-response water-temperature sensor
• 2 kW of power for great deep-water performance from the low frequency
• 2 kW low frequency: 38 to 75 kHz
  • 19° to 10° port-starboard beamwidth
  • 10° to 5° fore-aft beamwidth
  • Maximum depth of 1,829 m (6,000')
• 1 kW high frequency: 150 to 250 kHz
  • 25° constant beamwidth
  • Maximum depth of 152 m (500')
• 137 kHz of total bandwidth from one transducer
• Covers popular fishing frequencies of 50, 68, and 200 kHz plus everything else in the bandwidth
• High frequency delivers superior shallow-water performance, bottom detail, and fish-target separation
• High wide beamwidth yields more coverage for detecting fish in the upper-water column
• Urethane housing designed for custom mounting in a cavity
• Also available in an external (R109LHW) mount
• Exclusive Xducer ID® technology

Specifications:

• Weight: 13.6 kg (30 lb.)
• Recommended Boat Length: 12 m (40') and above
• Hull Material: Solid fiberglass only
• Hull Deadrise: Accommodates any deadrise angle based on custom cavity construction
• Acoustic Window: Epoxy/urethane
• Transducer Element: 16 internal broadband ceramic assemblies

DX900+ Multilog Smart™ Electromagnetic Speed Sensor Thru‑Hull NMEA 0183

Say goodbye to the paddlewheel and hello to Smart® Sensor technology. The DX900+ uses electromagnetic technology to accurately measure dual-axis speed through water plus immediately calculate leeway travel. Paddlewheels need cleaning and only measure speed longitudinally. The DX900+ measures water flow at 360° and will immediately deliver the leeway data to your instrument. There are no moving parts to clean or maintain. Performance sailors, racers, or long-distance cruisers will immediately see the benefits of the accuracy and reliability of the DX900+.

The DX900+ is available as a Speed and Water-temperature sensor.

Features:

• Electromagnetic dual-axis speed, and water temperature with no moving parts
• Measures transverse and longitudinal speed that instantaneously calculates leeway angle and speed through water with no latency
• Connects and shares data wirelessly with AIRMAR’s CAST™ app. Perfect for displaying performance data on phones or tablets, plus makes calibration fast and easy.
• Outputs heel and trim
• The sensing pins in contact with the water are made from very high-quality alloy, allowing very stable measurements and high resistance to corrosion. (Do not use any bottom paint on exposed sensing pins.)
• Thru-hull, low-profile housing with water valve
• Retractable insert for safe storage
• Available in a plastic (P717V) or stainless steel (SS617V) housing
• Retrofits to existing P617V housing

Specifications:

• Weight (sensor, box, and cable):
  • Plastic—1 kg (2.3 lb.)
  • Stainless steel—2 kg (4.4 lb.)
• Hull Material: Plastic housing for fiberglass or metal hull/Stainless steel housing compatible with all hull materials
• Deadrise Angle: Up to 22°
• Hole Diameter: Fiberglass or wood—51 mm or 2", Stainless steel housing in metal hull—57 mm or 2-1/4"
• Transverse Speed Range: ±6 knots
• Longitudinal Speed Range: ±60 knots
• Accuracy of Transverse and Longitudinal Speed: ±0.1 knots for speeds under 10 knots, ±1% for speeds above 10 knots
• Display Resolution: 0.01 knots
• Outputs: NMEA 0183—speed and temperature
• Configurable Data Update Rate: Up to 10 Hz
• Operating Temperature Range: -15°C to 55°C (5°F to 131°F)
• Water Temperature Accuracy: +0.5°C (+1.0°F)
• Power: Supply Voltage: 9 to 16 VDC
• Average Power Consumption: NMEA 0183 - 2.5 W
• Standard Cable Length: NMEA 0183 - 6M (20')
• Includes: Blanking plug
• CE Compliant: Yes to IEC60945

TM260-9N Transom Mount Transducer 1kW 50/200kHz 9-Pin for Navico

TM260 takes the legendary performance of the B260 to your vessel’s transom. This top-of-the-line 1kW transom-mount brings crystal clear imaging to any of today’s fishfinders. The large 200 kHz element and the seven-element 50 kHz array are excellent for bait and game fish separation along with detecting ground fish holding tight to the bottom. The TM260’s high-performance mounting bracket is easy-to-install and has a streamlined shape that delivers high-speed performance up to 30 knots (35 MPH).

Fishing Applications:

• Blue-water trolling using 50 kHz
• Deep-water bottom and wreck fishing up to 800 m (2,625’)

Features:

• Top-of-the-line narrow-beam transom-mount
• Designed for bottom fishing
• Wide 19° beam at 50 kHz
• Narrow 6° beam at 200 kHz
• Interfaces to any 600 W or 1 kW sounder
• The depth and fast-response water-temperature sensor
• Kick-up assembly locks in the “up” position and will not damage the transom
• Accommodates transom angles between 3° and 21°
• Urethane housing
• Boat Size: Up to 12 m (40’)

Raymarine RV-220S RealVision 3D Starboard Side Thru-Hull CHIRP Bronze Transducer - 20 - 2M Cable [A80469]

RV-220S RealVision 3D™ Starboard Side Thru-Hull CHIRP Bronze Transducer - 20° - 2M Cable - Replacement transducer

The RV-220 system features rugged cast-bronze thru-hull bodies suitable for fiberglass or wooden hulls. One transducer transmits and receives to port and downward, the other to starboard and downward, ensuring a full 180° of underwater coverage even on boats with deep keels or other underwater protrusions.

Features:

• Gyro-stabilized sonar technology: Gyro stabilization compensates for boat movement, delivering lifelike 3D sonar imagery.
• Wide spectrum CHIRP sonar: Transmits on 60 different frequencies for the most lifelike sonar imagery and simply the best fish targeting – hands down!
• Easy fish identification: Easily identify structure and locate fish with the lifelike clarity of RealVision™ 3D sonar
• Powerful four-channel sonar: Supports RealVision 3D, CHIRP DownVision, SideVision, high frequency CHIRP, and 600W  50/200kHz traditional sonar

PM275C-LHW CHIRP Transducer

Keel-mount 1kW dual-band CHIRP fishfinder transducer.

The PM265 is a Pocket/Keel mount unit available in the Low/Medium and Low/High bands. The PM275 is a wide beam version of the PM265 with Low/High bands and a wide beam.

Specifications:

• Type: CHIRP dual-band fishfinder transducer
• LM Version: Low Band 42-65 kHz / Beam width 25-16° // Medium Band 85-135 kHz / Beam width 16-11°
• LH Version: Low Band 42-65 kHz / Beam width 25-16° // High Band 130-210 kHz / Beam width 10-6°
• LHW Version: Low Band 42-65 kHz / Beam width 25-16° // High Wide Band 150-250 kHz / Beam width 25°
• Power Rating: 1000 watts
• Mounting: Pocket/Keel Mount
• Housing: Urethane
• Hull Aperture: 1.75" (44.5mm)

B744V 50/200 kHz Smart xSonic 9-Pin TH with Fairing Block

Bronze Thru-Hull with High-Speed fairing block. The Lowrance Bronze Thru-Hull, style B744V, 600w, multisensor provides accurate depth, speed, and temp readings and comes with a High-Speed Fairing Block. The high-speed fairing block provides a streamlined installation and allows for a vertical beam.

Compatible with Lowrance HDS, HDS Gen2, HDS Gen2 Touch, HDS Gen3, Lowrance BSM-1, Lowrance Hook, Simrad NSS, Simrad NSS evo2, and Simrad BSM-1.

Specifications:

• Temperature: Yes
• Speed Included: Yes
• Pins: 9
• Mounting Style: Thru-Hull
• Imaging: Standard
• Chirp: No
• Cable Length (Feet): 33'

Furuno CM275LH-W Urethane Pocket Mount Transducer - 12-Pin [CM275LH-W-12P]

Ships Direct From Manufacturer

CM275LH-W Urethane Pocket Mount Transducer - 12-Pin

Urethane, 1kW Tank/Cavity/Pocket Mount CHIRP Transducer with 12-Pin Connector, 42-65kHz and 150-250kHz.

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Furuno CA28BL-6HR FRP Transducer - 2kW - No Plug [CA28BL-6HR]

Ships Direct From Manufacturer

CA28BL-6HR FRP Transducer - 2kW - No Plug

FRP Transducer (BLT), Type 28BL-6HR, 2kW (No Plug)

Features:

• 28kHz FRP Transducer
• 2kW
• 22 x 32 degree Directional Pattern
• 15m Cable, no connector
• Weight = 6.5kg
• 120mm x 150mm x 123mm

Specifications:

• Beam Angle: 22 x 32 Degrees
• Housing Type: FRP
• Power Rating: 2kW
• Frequency: 28 kHz
• Install Type: External

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.
