Digital Yacht AISnode NMEA 2000 Boat AIS Class B Receiver [ZDIGAISNODE]

AISnode NMEA 2000 Boat AIS Class B Receiver

AISnode is the first AIS Receiver to be designed exclusively for NMEA 2000. With a single, integral 0.75m NMEA 2000 cable that takes power from the network and outputs the AIS data on to the network, the AISnode is incredibly easy to install. Just find or fit a spare NMEA 2000 "T Piece", screw the AISnode cable to the connection, connect a VHF antenna and the installation is complete.

Utilizing the same high performance, true dual channel receiver that our latest Class B Transponders have, AISnode will receive every AIS equipped vessel within VHF range and never miss or drop a single target. All of the latest NMEA 2000 AIS message types are supported, including AIS SARTs, AtoNs and Class B static data, ensuring full compatibility with all of the latest AIS enabled chart plotters.

NMEA 2000 is becoming more and more popular on new boats and nearly all new chart plotters have an NMEA 2000 interface, with one or two models only providing an NMEA 2000 interface. With its reliability, easy plug and play connectivity and industry standard compatibility, it is not surprising why NMEA 2000 is gradually replacing the older NMEA0183 standard.

The AIT2000 and AIT3000 Class B Transponders already provide NMEA 2000 connectivity but not all customers want the extra expense of purchasing and installing a transponder and for small chart plotters an AIS receiver is still a popular choice.

Features:

• Application Domain: For Boats
• Type: Class B Receiver

Specifications:

• Display Included: No
• GPS Included: No
• Function: Receive Only
• Antenna Included: No
• AIS Class: B
• Box Dimensions: 4"H x 7"W x 10"L WT: 1 lbs
• UPC: 081159830403

SAS-900 6" Color Class A AIS Transceiver

Internationally Certified SOLAS Class A AIS Transceiver

SAS-900 is the world's most sophisticated and robust SOLAS and Inland-Waterway certified AIS Class A Transceiver.

Fourth generation AIS technology delivers unmatched real world AIS receive, transmit and message processing performance and reliability. Quality engineered and manufactured without compromise, with features such as IPX7 weather proofing and integrated shock and vibration protection for continuous long term operation in even the harshest commercial or military environment.

A large integrated high definition color screen maximizes the benefit of the SAS-900's powerful Electronic Chart display engine with full detailed chart AIS overlay, and multiple target management functionality, including innovative MOB features and many more.Charts are C-Map Max software in MicroSD card.

Specifications:

• GPS Included: Yes
• Function: Receive/Transmit
• Display Included: Yes
• Antenna Included: No
• AIS Class: A
• Box Dimensions: 5"H x 10"W x 15"L WT: 6.3 lbs
• UPC: 010407421063

**As the FCC requires all units sold in the US to be programmed by a qualified technician. Please submit the form below for programming at the time of purchase. A copy of the MMSI registration or FCC Ship Station License is required, along with the vessel master or owner's signature on the completed programming form.**

Click here to download form.

AIT6000 Class B+ AIS Transponder

Nucleus Class B + AIS Transponder with SPAIS satellite AIS compatibility, alerts & an integrated NMEA 2000 wifi Gateway.

The AIT6000 is Digital Yacht’s Class B+ AIS transponder, set to replace the AIT5000. It retains all the features that made the AIT5000 successful—an integrated and patented ZeroLoss VHF antenna splitter, 5W SOTDMA transmissions, and NMEA 0183, NMEA 2000, wireless, and USB interfaces—while introducing several major innovations:

SPAIS Satellite Tracking

The AIT6000 incorporates Digital Yacht’s latest SPAIS™ (space AIS) technology with AIS transmissions now enabled for reception by AIS satellites. This functionality can be easily enabled from the set up menu and will prioritise your AIS transmissions for satellite reception, ideal for offshore and ocean sailors.

Integrated NMEA 2000 Gateway

The AIT6000 has also been designed to become an onboard hub for navigation.  It features NMEA 0183 and NMEA 2000 connectivity for modern navigation systems. It also has PC connectivity via USB and a wireless interface supporting up to 7 tablets or phones which can utilise the data for app integration.

AIT6000 adds a lot of interfacing capability through this WiFi interface with not just AIS and GPS data from the transponder being sent but also boat instrument data from the NMEA 2000 network thanks to its internal NMEA 2000 multiplexer – such as depth, heading, speed and wind information.

Built-In Collision & Anchor Alarms

The AIT6000 also has a built in interface accessible via any connected device for diagnostics, silence of AIS transmissions and also alerts for anchor drift and AIS closest point of approach (CPA) and time to CPA (TCPA).

These alarms can be monitored through the wireless interface with an attractive graphical display of current status or NMEA 2000 alerts can be sent over the NMEA 2000 network for pop up notifications or NavAlarm audible activations. This allows navigators to receive critical collision-avoidance warnings even when a chartplotter is not in use.

There is also a switched output on the AIT6000 power data cable which allows the alarm to attach to a sounder, relay or connect to a 3rd party system for alert activation.

Web Interface with Integrated Alarms

Installation is simple with an integrated and patented zero-loss VHF antenna splitter so the main VHF antenna is used for both AIS and VHF operation.

CLA2000 Deep Sea Class A AIS Transponder

Digital Yacht’s CLA2000 is the ultimate SOLAS and inland waterway globally approved Class A AIS transponder. Water and weather proof to IP67, it has a full integrated 5” hi-res colour display supporting a wide range of functionality including electronic chart navigation with optional C-Map MAX charting and AIS target management.

Proven, superior real world AIS message receive and transmit and message processing performance is delivered by advanced core SDR AIS technology. This state of the art technology ensures you see more targets, more of the time and at maximum range.

The CLA2000 will find applications on SOLAS mandated vessels over 300GRT as well as workboats, rescue services, inland waterways users, RIBs, large yachts and any user wanting premium AIS performance and safety.

The CLA2000 has optimised software for detecting AIS SART and MOB devices with a dedicated icon for this class of AIS. An automatic alarm is activated on detection of an AIS SART beacon activation. The target plot display will also calculate relative bearing of the device for easy visualisation of the target and rescue.

The CLA2000 is fitted with a micro SD card reader located behind a waterproof cover on the front panel. This can support software updates, data logging of AIS and position data to a blank card as well as compatibility with C- Map MAX charting cards for optional detailed back ground charting.

The CLA2000 has an integrated wireless interface for sending AIS and position data to smart phones, tablets, PCs and MACs for use with 3rd party charting and navigation apps. It supports client mode where it can connect to an existing wireless network or AP mode where devices can connect directly to the CLA2000. Up to 5 simultaneous/connected devices are possible.

Features:

• Globally approved Class A AIS transponder
• High resolution, 800 x 480 pixel 5” colour display (MKD) with easy to use, fast user interface
• Bracket or flush mount – waterproof to IPX7
• Integrated GPS with external antenna or utilise external NMEA feed (user selectable)
• 3 x NMEA 0183 interface (bi-directional for plotter, ECDIS, radar etc)
• 3 x sensor input ports (eg BlueBoard, external GNSS, gyro etc)
• NMEA 2000 interface
• Built in SD card slot for software updates, AIS data port logging or C-Map MAX mapping capability with optional C-Map data card
• Built in wi-fi for connection to iPads and tablets for wireless navigation
• Sophisticated AIS SART MOB alarm and display capability
• User programmable alarms for CPA and TCPA
• Advanced filtering of targets
• External alarm and remote silence switch capability

Specifications:

• GPS Included: Yes
• Function: Receive/Transmit
• Display Included: Yes
• AIS Class: A
• Box Dimensions: 5"H x 10"W x 16"L WT: 6.25 lbs

Digital Yacht AIT2500 Class B+ 5W SOTDMA AIS w/GPS [ZDIGAIT2500]

**As the FCC requires all units sold in the US to be programmed by a qualified technician. Please submit the form below for programming at time of purchase. A copy of the MMSI Registration or FCC Ship Station License is required along with the vessel master or owner's signature on the completed programming form. **

Click here to download form.

AIT2500 Class B+ 5W SOTDMA AIS with GPS

Digital Yacht have a range of Class B+ AIS transponders. Class B+, a standard, utilizes SOTDMA format transmissions which offer a 5W power output (2.5x more powerful than a regular Class B), a guaranteed time slot for transmission in busy traffic areas and faster update rates depending upon the speed of the vessel. It’s ideal for ocean sailors requiring the best possible performance and future proof satellite tracking applications, fast power boats and smaller non-mandated commercial vessels. It still inter-operates with existing Class B and Class A systems.

The AIT2500 is a full function SOTDMA AIS transponder with NMEA 0183, NMEA 2000 and USB data outputs. It is supplied with a GPS antenna and requires connection to a VHF antenna or suitable VHF-AIS antenna splitter.

The AIT2500 has the option of an AIS SART alarm which is great for use with personal AIS MOB devices.

Specifications:

• Class B+ 5W transponder with GPS/GLONASS positioning
• Multiple NMEA 0183 in/out and multiplex capability
• NMEA 2000 connectivity
• USB connectivity for PC/MAC
• Remote TX silence switch option
• Supplied with GPS antenna
• Options include VHF-AIS antenna splitter, wireless interface (WLN10SM) and AIS SART Alarm (AIS Lifeguard)

Note On SOTDMA Technology

Class B+ is a generation of AIS functionality based on SOTDMA (self organised TMDA) messaging rather than the simpler CSTDMA (carrier sense TDMA).  It guarantees your AIS transmission will get a time slot, even in areas of very high traffic density.  It also specifies a 5W transmission power (compared with 2W for Class B) and a transmission rate that increases as the vessel moves faster.  With regular Class B protocol, the transmission rate is fixed at every 30 seconds when the vessel is moving. It is ideal for ocean sailors requiring the best possible performance and future proof satellite tracking applications, fast power boats and smaller non-mandated commercial vessels.

B921 Class B AIS Transceiver - 2W CSTDMA

**As the FCC requires all units sold in the US to be programmed by a qualified technician. Please submit the form below for programming at the time of purchase. A copy of the MMSI registration or FCC Ship Station License is required along with the vessel master or owner's signature on the completed programming form.**

Click here to download form.

The B921 is a 2W CSTDMA Class B AIS transceiver, delivering em-trak's advanced performance and reliability through next-gen technology. Small and durable, this trusted transceiver processes all AIS transmissions in real-time, even at the range limit, so you always have the complete picture and the time to respond.

em-trak's intelligent connectivity means the B921 can be connected to any chart-plotter and comes equipped with integrated GPS technology and best-in-class, ultra-low power consumption. Installation is also simplified with our unique FLEXI-FIT® bracket system to have you up and running in no time at all.

Features:

• Certified AIS Class B – 2W CSTDMA
• Global certification - USCG / FCC / Canada / Europe
• SRT-AIS™ Transceiver Engine for superlative proven performance
• FLEXI-FIT™ bracket system for easy, convenient, and secure installation
• Internal high-performance GPS receiver and antenna (external antenna optional)
• Water, pressure spray, and damp proof (IPx6, IPx7 certified)
• Protected from vibration, shock, and extreme temperatures
• Small and lightweight
• Ultra-low power consumption – best in class
• NMEA 0183 & NMEA 2000
• Automated health and performance monitoring
• Silent mode (transmit-off) function
• Enhanced RF screening to protect against electromagnetic interference
• Built-in power surge protection

Physical & Environmental Specifications:

• Size (H x W x D): 150 x 115 x 45mm
• Weight: 375kg
• Operating temperature: -25°C to +55°C
• Storage temperature: -25°C to +70°C
• Ingress protection: IPx6 and IPx7

Electrical Specifications:

• Supply voltage: 12V or 24V DC
• Supply voltage range: 9.6V - 31.2V DC
• Average current (at 12V): 135mA
• Peak current: 2A
• Average power consumption (at 12V): 1.6W
• Galvanic isolation: NMEA 0183, NMEA 2000, VHF antenna port

Connectors:

• VHF antenna: SO-239
• GNSS: TNC
• Power: 12-way circular multipole
• NMEA 2000: 5-way Micro-C connector
• USB: USB Micro-B

Data Interfaces:

• NMEA 0183: 2 x bi-directional ports
• NMEA 2000: NMEA 2000 Ed 3.101, LEN=1
• USB: PC virtual com port for NMEA 0183 data

Standards Compliance:

• AIS standards: IEC 62287-1 Ed. 3, ITU-R M.1371.5
• Product safety standards: EN60950-1 2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013 EN62311:2008
• Environmental standards: IEC 60945 Ed. 4
• Serial data interface standards: IEC 61162-1 Ed 5.0, IEC 61162-2 Ed 1.0
• NMEA 2000: NMEA 2000 Ed 3.101
• GNSS performance standards: IEC 61108-1 Ed 2.0, IEC 61108-02 Ed 1.0

GNSS:

• Systems supported: GPS, GLONASS, BeiDou, Galileo (two of any combination, three including GPS, Galileo)
• Channels: 72
• Internal/external antenna: Internal or optional external antenna
• Time to first fix from the cold start: 26s

VHF Transceiver:

• VDL access scheme: CSTDMA
• Operating frequency: 156.025MHz - 162.025MHz
• Channel bandwidth: 25kHz
• Receivers/transmitters: 2 x receivers, 1 x transmitter
• AIS receiver sensitivity (20% PER): -111dBm
• AIS transmitter power: 2W (+33dBm)

User Interface:

• Indicators: Power, transmit timeout, error, silent mode

In the Box:

• 1 x AIS transceiver
• 1 x Power and data cable (2M)
• 1 x FLEXI-FIT™ mounting bracket
• Complete with screws & optional fixing tape

Specifications:

• AIS Class: B
• Antenna Included: Yes
• Display Included: No
• Function: Receive/Transmit
• GPS Included: Yes
• Box Dimensions: 6"H x 7"W x 8"L WT: 1.55 lbs
• UPC: 672975210502

P200-SO AIS Class B with Display

**As the FCC requires all units sold in the US to be programmed by a qualified technician. Please submit the form below for programming at the time of purchase. A copy of the MMSI Registration or FCC Ship Station License is required, along with the vessel master or owner's signature on the completed programming form.**

Click here to download form.

Smart Charting with integrated 5W AIS class B.

The P200-SO is a globally certified chart plotter with integrated 5W AIS class B. The application running on the P200 series is the latest milestone of AMEC´s software technology. It features a powerful charting engine with an intuitive user interface and advanced navigation functions for enhanced safety and eased voyage. P200’s hardware with IP67 waterproof and ergonomic interface ensures a reliable operation in a rough marine environment.

Features:

• Globally certified 5W SOTDMA AIS Class B with display
• Powerful 72-channel GNSS receiver supporting GPS and GLONASS
• Ruggedized for marine environment - IP67 and damp, shock, vibration, and temperature proved
• Integrated high definition colour display with pinch-to-zoom multi-touch operation
• Ergonomic backlit button and arrow keys
• Supporting C-MAP 4D chart (micro-SD) with AIS target overlay
• Rich alarm functionality – CPA/TCPA, MOB & SAR
• Chart view and plot view for enhanced situational awareness at sea
• NMEA 0183, NMEA 2000 & optional Ethernet connectivity

Specifications:

• AIS Class: B
• Antenna Included: No
• Display Included: Yes
• Function: Receive/Transmit
• GPS Included: No
• Box Dimensions: 8"H x 8"W x 11"L WT: 4.6 lbs
• UPC: 4713095730085

PLOMO-500 AIS Sart (Search & Rescue Transponder)

The Latest SART Technology

AMEC AIS SART (Search And Rescue Transmitter) PLOMO-500 complies with IEC 61097-14 specification. It is designed to be an alternative to Radar SART. PLOMO-500 can transmit GPS positions, Unique ID, COG, and SOG every minute once activated. It allows the rescue team to locate the survivors rapidly through the broadcasted AIS information and, ultimately, gives the survivors a better chance to survive.

User-Friendly Operation

AMEC PLOMO-500 is not only the AIS SART itself but also a complete survival/distress solution of all other essential accessories of AIS SART. The solution comes in a survival bag, and during emergency times, it is all what user needs to carry on his/her back. The setting operation is easy; it only requires 4 simple steps.

Backlit Panel and LED Indicator Integration

AMEC PLOMO-500 has a backlit operational panel, which allows users to see the buttons in a dusky environment. Moreover, the main unit has an overusage design to indicate if the battery life has been compromised due to excessive testing or it had been activated previously. Also, to increase the chance of survival, the unit’s LED indicator signals an “SOS” distress message during activation for the survivors to be easily spotted by the rescue team.

Features:

• Innovative AIS Technology
• Rugged and compact design
• Buoyant/floatable and waterproof to 10m
• Fluorescent backlight panel
• SOS LED light
• Easy to assemble and carry
• Minimum operating life - 96 hours

Specifications:

• Battery Replacement (Years): 6
• Floats: Yes
• Operational Life (Hours): 96
• Box Dimensions: 4"H x 7"W x 16"L WT: 2.6 lbs
