Boat Outfitting - Steering Systems

HYTECH 1.1 Front Mount OB System up to 175HP - Includes UP20 FM Helm, 2qts of Oil, UC95-OBF Cylinder & 40' Tubing

The HYTECH steering kit featuring the unique split tilt tube rod that allows for installation of the UC94 cylinder without removing the engine. The HYTECH is an easy and affordable outboard hydraulic steering solution for boats with 175 horsepower and under. Coupled with the composite UP20 helm, the HYTECH offers effortless steering with 5 turns lock to lock. And, it is applicable to almost all 2 and 4 stroke outboard engines.

Kit Contains:

• UP20 FM Helm
• UC95-OBF cylinder
• OIL 15 - 2 Quarts
• 40' of cut to length tubing

Uflex UC81-OBF Front Mount Outboard Cylinder [UC81-OBF]

UC81-OBF Front Mount Outboard Cylinder

UC81 OBF – Balanced: the number of turns lock-to-lock is equal port to starboard and vice-versa. Front-mount cylinder for outboard engines up to 115 hp. Replaceable end caps.

Specifications:

• Volume: 81 cc - 4.9 cu. in
• Output force: 222 kg (489 lbs)
• Inside diameter: 27,4 mm (1.08")
• Stroke: 186 mm (7.3")
• Fittings for high-pressure flex hose: 3/8"
• Bleed fittings: DN5 quick connect

MasterDrive Steering System - Single Station/Twin Cylinder Kit - UC128TS - SVS 1 & UC128TS - SVS 1P Cylinders

The MasterDrive power-assisted outboard steering system delivers effortless steering for the most demanding applications, regardless of speed or torque conditions.

Features:

• Eliminates torque at the steering wheel
• Three different selectable levels of power give the driver the desired feeling on the wheel (PATENTED)
• Automatically reverts to manual mode in case of power loss
• High efficiency, low Amp draw, low noise

Kit Includes:

• UH40-F - MasterDrive 40cc front mount helm
• UCMD - MasterDrive user interface
• UPMD - MasterDrive power unit 12V DC
• UC128TS - SVS 1 front mount cylinder
• UC128TS - SVS 1P front mount cylinder
• OIL 15 - 4 quarts

Uflex Twin Cylinder Adjustable Tiebar 26'-32' - Mercury/Yamaha [A95 M/Y-32]

Twin Cylinder Adjustable Tiebar 26'-32' - Mercury/Yamaha

For twin OB engines/Dual cylinder, Allows to tilt the engines independently, it’s also available in semi-assembled bars and brackets, stainless steel components.

Features:

• 2 different lengths available: From 26” (660,4 mm) to 32” (818,8 mm) twin engine centers and from 32” (818,8 mm) to 37.5” (952,5 mm) twin engine centers
• Suitable for applications with dual UC128– OBF or UC130–SVS front mount cylinder
• Allows the engines to tilt independently
• All stainless steel components
• Electropolished stainless steel ball joints

Uflex UC215-I Cylinder 215cc 9" Stroke Aluminum Uses KITOB SVS Hoses [UC215-I]

UC215-I Cylinder 215CC 9" Stroke Aluminum Uses KITOB SVS Hoses

Balanced: the number of turns lock-to-lock is equal port to starboard or vice-versa.

Specifications:

• Volume: 215cc - 13.12 cubic inches
• Torque: 111 kgm (9652 lbs.in)
• Output force: 673 kg (1483 lbs)
• Internal diameter: 40 mm (1.57")
• Stroke: 228 mm (9")
• Fittings for high-pressure flexible hose: 3/8" (9,5 mm)

Uflex PROTECH 3.1 Front Mount OB Hydraulic System - Includes UP28 FM Helm, Oil  UC128-TS/3 Cylinder - No Hoses [PROTECH 3.1]

Ships Direct From Manufacturer

PROTECH 3.1 Front Mount OB Hydraulic System - Includes UP28 FM Helm, Oil & UC128-TS/3 Cylinder - No Hoses

Durability and performance define the Protech front mount outboard steering package. From the stainless steel helm shaft, heavy-duty shaft seals, carbon steel piston, and 304 electropolished and passivated stainless link assemblies, the Protech is built for maximum longevity and peak performance. Adjustable boss-style fittings allow precise hose routing without the risk of breaking the fittings by overtightening or leaking fittings from loosening during installation, a common problem on competing cylinders.

Kit Contains:

• UP28 F Front mount helm pump
• UC128-TS/3 Cylinder Front mount outboard cylinder
• OIL 15 Hydraulic oil - 2 quarts
• The wheel is not included

Uflex 12x12 Polished Stainless Steel Trim Tab Kit [MTCP1212LPJ]

Ships Direct From Manufacturer

12x12 Polished Stainless Steel Trim Tab Kit

Improve fuel economy and passenger comfort with Uflex electromechanical trim tabs. Featuring electropolished stainless steel planes and low consumption, high speed, composite actuators, these tabs are built to last in the most demanding sea conditions.

Uflex trim tabs have been specifically designed for easy installation using a quick connect bracket actuator, requiring only one small hole per tab through the transom. The patented transom mounting bracket encapsulates the wiring to ensure protection against any wiring damage.

Uflex SilverSteer Front Mount Outboard Hydraulic Steering System - UC130 V2 [SILVERSTEERXP2]

Ships Direct From Manufacturer

SilverSteer™ Front Mount Outboard Hydraulic Steering System - UC130 V2

Specifically designed for high performance and high torque applications, the SilverSteer features a 1,500 psi helm and keyed bullhorns on the cylinder for maximum durability and minimal lost motion.

Whether a bass boat, flat boat or tournament style offshore fishing boat, the SilverSteer™ will deliver smooth, responsive and precise steering.

Adjustable boss style fittings allow precise hose routing without the risk of breaking the fittings by over tightening or leaking fittings from loosening during installation, a common problem on competing cylinders.

Specifications:

• Volume: 130 cc - 7.93 cu.in
• Output force: 492 kg - 1085 lbs
• Inside diameter: 36 nm - 1.43"
• Stroke: 185 nm - 7.28"
• 3/8" fittings: For high pressure flex hose
• Bleed fittings: DN5 quick connect

Kit Includes:

• UC130-SVS 2
• UP25F-SVS
• 2x Oil 15

Quick Guide (pdf)
Brochure (pdf)
