Compass Touch Toilet - Low, White - 12V

The narrow footprint and smart back of the Compass toilet give maximum space and maximum flexibility wherever it is installed on board. It can go straight to a wall or even further towards the hull thanks to the cutaway. The Compass is not limited by a vertical back. This way, the visual installation remains perfect with whatever installation space you have. The small footprint and the hose design facilitate a very easy installation. The discharge pipes can easily be connected either below the step or surface-mounted in all directions. By having both a high and a short profile, the Compass range offers maximum flexibility on board.

The performance of the macerator pump meets all quality standards, while the technology inside the toilet has been further developed to keep the sound emission to the lowest level possible, while limiting the water and electrical consumption to minimal levels. The installation, plumbing, and wiring are easy and fast, with virtually no maintenance.

Both the Compass High and Short versions are equipped with an innovative soft closing system. A gentle finger touch to the lid activates the soft-close damper mechanism, which controls the closing speed of the cover. In addition to user convenience, a slow-closing lid keeps noise to a minimum and prevents potential damage to the toilet seat.

The soft-close damper mechanism is a design original to Tecma.

Features:

• Italian ceramic
• Wide range of control panels (Touch SFT panel included, others sold separately)
• Silent flush
• Low consumption

Technical Specifications:

• Weight - 40 lbs
• Water Usage - 0.5-2L/0.1-0.5 gal per flush
• Color - White
• Seat and Cover - Thermosetting with soft closing
• Outlet Pump - MAC 4 12/24V
• Inlet Device - Solenoid

Specifications:

• Color: White
• Inlet Size: 1/2"
• Operation Method: Electric
• Outlet Size: 1/4"
• Rinse Water: Fresh
• Size: Compact Size
• Suction Lift (ft.): 13'
• Type: Toilet
• Volts: 12v
• Box Dimensions: 19"H x 24"W x 25"L WT: 52.6 lbs
• UPC: 850080338339

Thetford Nano Eco Compact Toilet - 12V [T-NAN012PW/E/NA]

Nano Eco Compact Toilet - 12V

The Tiny Turbo Toilet!

From the experts in macerating toilets, Nano toilet utilizes Turbine Technology to produce a powerful, clog-resistant flush. This model is the ultimate combination of a highly efficient marine toilet and the smallest design capable to offer the same comfort as bigger units. It’s the result of a strong relationship with the market and fulfills new requirements for vessels below 50′ (45m). Thetford Marine product development team has created a design that is extremely elegant, but also very flexible to install, thanks its compact size.

The performance of the macerator pump meets all quality standards, while the technology inside the toilet has been further developed to keep the sound emission to the lowest level possible, while limiting the water and electrical consumption to minimal levels. The installation, plumbing and wiring is easy and fast, with virtually no maintenance. The toilet can be operated in combination with two different control panels: Eco rocker switch and Premium Plus.

Features:

• Uses 2 check valves and this combined with a water trap ensures there are no odor issues
• Incredibly quiet operation
• Can use both raw water and pressure water flush
• Leaves a clean, dry bowl after every powerful flush
• Optional User-friendly Eco rocker switch (to reduce energy and water consumption) or a smart flush controller with high-end flush and tank control features (sold separately)

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

• Color: White
• Gallons Per Minute: 3 GPM
• Inlet Size: 1/2"
• Operation Method: Electric
• Outlet Size: 1.5"
• Rinse Water: Raw/Fresh
• Size: Compact Size
• Suction Lift (ft.): 13'
• Type: Toilet
• Volts: 12v
• Box Dimensions: 17"H x 17"W x 21"L WT: 45 lbs
• UPC: 028985002840

Owner's Manual (pdf)

Complete Purasan EX Treatment System - 12V

Raritan Purasan Waste Treatment System is suitable for all marine sanitation needs. The Purasan EX was originally developed for the freshwater lakes in Kentucky as an alternative to the Lectra/San.

This Type I Marine Sanitation Device (MSD) has become increasingly popular with many users in both salt and freshwater. Raritan believes that treating a single flush at the source and discharging into tidal water is far more effective than risking having a holding tank dumped overboard when a pump-out cannot be found or is not functioning. Each user has unique needs when boating and for many a holding tank may be the best solution while some prefer to treat and discharge. There are a few things to consider when choosing a Type I MSD.

While Treatment is required inside the three-mile limit there are areas that prohibit discharge from Marine Sanitation Device. The areas that do not allow discharge of any type are called No Discharge Zones and these zones are specific, at this time, to treated black water only. So, any vessel operator or owner should consider the amount of time spent cruising, the areas in which they will be cruising and the availability of pumpouts. A holding tank should never be discharged overboard.

The Purasan EX is a flow through system which means that the toilet is connected to the tank and the tank is connected to the thru-hull. With each flush of the toilet the waste enters the tank where a small amount of disinfectant is introduced to neutralize the waste. At the same time an equal amount of treated waste is forced out of the tank and overboard.

Purasan Improvements

The tablets used are very similar to the mixture used in commercial waste water treatment plants. When the toilet flushes a small amount of water is run over the tablets to create a disinfectant that drains into the tank and a high-speed macerator inside the tank breaks down waste and ensures that the disinfectant comes in contact with the waste.  This system does require the user to buy tablets to keep the system functioning properly. While the original Purasan remained largely unchanged for a long time the newest version the Purasan EX has added a control that will notify the user when tablets need to be added.

Another improvement in the Purasan EX over the original design is the addition of an air pump that forces the water down into the treatment tank. This makes mounting of the system easier and prevents the tablets from disintegrating too fast. While it was originally designed for just freshwater use and for use with specific toilets it can now be used with almost any marine toilet. The only freshwater required is the water that passes over the tablets. However, toilets can flush with either salt or freshwater.

Marine Elegance™

The Marine Elegance is the ultimate in electric marine toilets. Offering the luxury of a full size seat in a one piece china bowl developed with a unique mounting system. It offers a super small footprint at just 8 ½” x 9 ¾”.  All toilets are now supplied with a slow close toilet seat that includes stops to help prevent the seat from shifting while in use during heavy seas. With the same Vortex-Vac technology also offered in the Atlantes Freedom, it creates a vacuum in the bowl, eliminating the need for extra vacuum generation equipment. Unlike typical vacuum toilet systems, a convenient, built-in shredder with stainless steel blades transforms waste into small particles to reduce clogs. The efficient action of the pump quickly and quietly pulls waste from the bowl with the ability to push the waste an amazing 10' vertically and 100' horizontally. Performing at a noise level less than 63 decibels it won’t alert everyone in the boat or on the dock that nature is calling.

Benefits:

• Low water usage
• Small footprint for compact installation
• One piece vitreous china bowl
• Angled back for contoured fit
• Quiet operation
• Unmatched rinsing capabilities
• Low water consumption
• Built in shredder reduces clogs
• Can pump 10ft vertically, or 100ft horizontally

The Raritan Programmable Smart Toilet Control:

The Raritan Smart Toilet Control is a fully programmable flush control. The control allows users to flush the toilet with no water, a small amount of water or a fully timed flush. the timed flush feature can be adjusted on the panel without having to remove any components.

• Normal Flush - starts a timed flush, walk away and the toilet will run through a sequence of intake and discharge modes ensuring maximum bowl rinse, bowl re-fills to leave water in the bow
• Water Saver - starts a timed flush using half of the water of a normal flush. Bowl refills to leave water in the bowl.
• Water Only - adds additional water to the bowl without discharging any of the contents of the bowl. Allows the user to wet the bowl prior to use or fill the bowl to a certain level to minimize water usage.
• Empty Only - allows the user to evacuate the bowl while using no water. While the button is pressed the discharge pump will run, when released the pump stops.

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Color: White
• Gallons Per Minute: 3 GPM
• Inlet Size: 1/2"
• Operation Method: Electric
• Outlet Size: 1"
• Rinse Water: Fresh
• Suction Lift (ft.): 4'
• Volts: 12v
• Type: Toilet
• Size: Household Size
• Box Dimensions: 20"H x 21"W x 24"L WT: 49 lbs
• UPC: 085462024597

MasterFlush 8740 White Electric Macerating Toilet - Raw/Fresh Water

Enjoy the upscale look and user-friendly performance of a premium residential toilet with the Dometic™ 8700 series of MasterFlush toilets. The elongated seat with Slow-Close Action and deep bowl provides ultimate comfort, and the high-performance macerator pump assures thorough flushing every time while operating 30% more efficiently than other macerator heads.

Features:

• Powerful macerating flush
• Quieter, shorter flush duration than other macerator toilets
• Two flush options: Normal or Low allow efficient water consumption
• Standard-height toilet with residential-size bowl and elongated seat for premium comfort
• Through-the-floor or through-the-wall discharge fittings
• Dometic™ Flush Touch Pad

Technical Specifications:

• Dimensions - 21.5" (D) x 19" (H) x 14.75" (W)
• Weight - 41.5 lbs
• Input Voltage - 12v
• Flush Method - Electric wall switch
• Material - Ceramic

WARNING: This product can expose you to chemicals including ARSENIC which is known to the State of California to cause cancer or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Color: White
• Operation Method: Electric
• Rinse Water: Raw/Fresh
• Size: Household Size
• Suction Lift (ft.): 9.8
• Volts: 12v
• Box Dimensions: 16"H x 22"W x 23"L WT: 50.35 lbs
• UPC: 0713814269043

Marine Elegance™

The Marine Elegance is the ultimate in electric marine toilets. Offering the luxury of a full size seat in a one piece china bowl developed with a unique mounting system. It offers a super small footprint at just 8 ½” x 9 ¾”.  All toilets are now supplied with a slow close toilet seat that includes stops to help prevent the seat from shifting while in use during heavy seas. With the same Vortex-Vac technology also offered in the Atlantes Freedom, it creates a vacuum in the bowl, eliminating the need for extra vacuum generation equipment. Unlike typical vacuum toilet systems, a convenient, built-in shredder with stainless steel blades transforms waste into small particles to reduce clogs. The efficient action of the pump quickly and quietly pulls waste from the bowl with the ability to push the waste an amazing 10' vertically and 100' horizontally. Performing at a noise level less than 63 decibels it won’t alert everyone in the boat or on the dock that nature is calling.

Benefits:

• Low water usage
• Small footprint for compact installation
• One piece vitreous china bowl
• Angled back for contoured fit
• Quiet operation
• Unmatched rinsing capabilities
• Low water consumption
• Built in shredder reduces clogs
• Can pump 10ft vertically, or 100ft horizontally

Heavy Duty Push Button Switch:

• Providing only the ability to flush with no independent control of water or discharge

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Color: White
• Gallons Per Minute: 3 GPM
• Inlet Size: 1/2"
• Operation Method: Electric
• Outlet Size: 1"
• Rinse Water: Fresh
• Suction Lift (ft.): 4'
• Volts: 12v
• Type: Toilet
• Size: Household Size
• Box Dimensions: 17"H x 24"W x 24"L WT: 47 lbs
• UPC: 085462024757

Comfort Height Marine Elegance with Pressurized Freshwater & Smart Toilet Control - White - 12V

Elevate Your Onboard Experience with the Comfort Height Marine Elegance Toilet

Navigating the challenges of marine sanitation can often be a daunting task for boat owners and crew. Raritan Engineering addresses these challenges head-on with the introduction of the Comfort Height Marine Elegance electric toilet. Designed with both functionality and comfort in mind, this innovative toilet ensures a more pleasant and hassle-free experience at sea.

Advanced Design & Superior Comfort

The Comfort Height Marine Elegance toilet features an elongated bowl and luxurious residential dimensions, providing unparalleled comfort while maintaining one of the smallest and cleanest footprints in the industry. Constructed from gleaming and easy-to-clean vitreous china, available in white or bone, the elongated bowl not only enhances comfort but also exudes elegance and durability. Hidden hardware contributes to a sleek, modern installation, adding a touch of sophistication to any marine setting. With a 16-1/2″ bowl height, this toilet offers a welcome change for boat owners accustomed to traditional, compact marine heads. The inclusion of a slow-close seat with stops prevents shifting, ensuring stability even when the vessel is underway.

Innovative Flush Options

Raritan’s Comfort Height Marine Elegance stands out with its versatile flush options. The Smart Handle, a residential-style side lever, allows for timed operation and independent control of water and discharge through intuitive push or pull actions. For enhanced convenience, the wall-mounted Smart Toilet Control is fully programmable, optimizing water usage according to individual preferences. Additionally, the Wireless Remote Bluetooth Control eliminates the need for complex wiring through bulkheads and cabinetry, allowing for programming from up to 50 feet away. The Multifunction Flush Panel offers momentary operation for fill, flush, and discharge, further simplifying the user experience.

Flexible Plumbing Configurations

To accommodate various marine plumbing setups, the Comfort Height Marine Elegance offers three distinct configurations. The Remote Pump model enables the use of outside water for flushing, providing flexibility for different water sources. The Pressurized Water Model utilizes onboard water with a minimum pressure/flow of 5 gpm and a maximum pressure of 150 psi, ensuring efficient operation. For maximum versatility, the SeaFresh option allows users to switch between onboard freshwater and outside raw water with a simple flip of a switch. Despite its powerful performance, the toilet operates quietly at only 63dB, thanks to its low-power internal shredder with stainless steel blades, which virtually eliminates clogging.

Easy Installation & Power Options

Designed for straightforward installation, the Comfort Height Marine Elegance is available in 12V, 24V, and 120/240V AC versions, catering to a wide range of power systems. Its compact footprint of just 10-1/4″ x 16-1/2″ ensures it fits seamlessly into various marine environments without compromising on space.

Electric Marine Toilet - Regular Bowl with Soft Close Lid - 12V

This versatile toilet brings the luxury of electric flushing aboard your vessel. It offers two options: a household size bowl for all the convenience of home, and a compact bowl where space is a premium.

Features:

• An integral self-priming rinse pump designed to bring sea, river or lake water into the bowl comes standard
• A flexible design makes it suitable for overboard or holding tank discharge
• A built-in backflow preventer guards against flooding and waste return
• Corrosion-resistant materials throughout permit fresh or salt water service
• Can be mounted 3' (1m) above or below the waterline with appropriate plumbing
• For use with sea, river or lake water only
• Regular Bowl size
• Composite - Soft Close lid
• Raw water
• Integral/Rinse Pump

Specifications:

• Size: Household Size
• Operation Method: Electric
• Color: White
• Volts: 12v
• Type: Toilet
• Box Dimensions: 17"H x 21"W x 21"L WT: 29.6 lbs
• UPC: 671880628334
