Marine Plumbing & Ventilation

Whale Seaward 11 Gallon Hot Water Heater - Stainless Steel - 120V - 1500W [S1200E]

Seaward 11 Gallon Hot Water Heater - Stainless Steel - 120V - 1500W

Whale Electric Water Heaters includes models with the very latest  technology. All heaters are manufactured from only highest quality materials and designed to specifically withstand harsh marine conditions.

The White Epoxy Coated Aluminum cases are well-suited to installation in many of today’s engine rooms. Their white appearance blends in well with existing equipment and the coated aluminum material offers corrosion resistance.

Features and Benefits

• Horizontal Mounting only
• Robust Manufacturing
• Hold down brackets welded to inner tank
• Safety controls
• Integrated pressure relief valve
• Temperature and pressure drain tube included
• Magnesium anodes available separately
• Recommended to prevent corrosion and ensure a longer Water Heater life
• Sturdy, robust exteriors
• Ignition protected

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Gallons: 11
• Heat Exchanger: No
• Volts: 120v
• Box Dimensions: 17"H x 17"W x 26"L WT: 31.4 lbs
• UPC: 766478948403

Owner's Manual (pdf)
Brochure (pdf)

Seaward 6 Gallon Hot Water Heater with Rear Heat Exchanger - 120V - 1500W

The White Epoxy Coated Aluminum cases are well-suited for installation in many of today's engine rooms. Their white appearance blends in well with existing equipment and the coated aluminum material offers.

Features and Benefits

• Multiple versions to suit your installation
• Robust Manufacturing
• Safety controls
• Magnesium anodes available separately
• Sturdy, robust exteriors
• Ignition protected

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Gallons: 6
• Heat Exchanger: Yes
• Volts: 120v
• Box Dimensions: 14"H x 14"W x 23"L WT: 24.6 lbs
• UPC: 766478947727

High Flow Dual Pump System - 12 VDC - 10.0 GPM

The most advanced system available. This fully-automatic, quiet unit delivers water smoothly and consistently.

Features:

• Replaces 5907

• System Delivers up to 10 GPM at Open Flow

• Includes the AQUA KING II Supreme 5.0 Pump and PRO BLASTER II Ultimate 5.0 Pump

• 12 VDC

• 55 PSI Shut-off Pressure

• Built to Withstand the Harsh Marine Environment with Electro-Coated Motor, O-ring Seals and Fully-Sealed Wire Entries

Specifications:

• Volts: 12v
• Max PSI: 55
• Gallons Per Minute: 10 GPM
• Box Dimensions: 7"H x 7"W x 24"L WT: 17.8 lbs

Whale Seaward 6 Gallon Hot Water Heater w/Front Heat Exchanger - Galvanized Steel - 120V - 1500W [F600]

Seaward 6 Gallon Hot Water Heater with Front Heat Exchanger - Galvanized Steel - 120V - 1500W

Whale Electric Water Heaters includes models with the very latest technology. All heaters are manufactured from the highest quality materials and designed to specifically withstand harsh marine conditions.

The Marine Galvanized Steel Cover offers corrosion resistance at an affordable price. This material weighs more than the other case options but is made from a strong and robust material.

Features and Benefits

• Robust Manufacturing
• Safety controls
• Magnesium anodes available separately
• Sturdy, robust exteriors
• Ignition protected

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Gallons: 6
• Heat Exchanger: Yes
• Volts: 120v
• Box Dimensions: 14"H x 14"W x 23"L WT: 24.6 lbs
• UPC: 766478947918

1700 Series Water Heater

120v

12 Gallon

With Engine Heat Exchanger

The "1700 Series" water heater provides hot water for galley and shower. Dense foam insulation provides better and longer heat retention than traditional fiberglass. The tank itself is protected by a 75 PSI T& P (temperature and pressure) relief valve. The cylindrical design of the tank enables it to withstand more pressure than a cube shaped tank.

Heat exchanger models can be connected to the engine cooling system. This provides the added convenience of hot water when underway or generator power is not available. The innovative heat exchanger is over seven feet in length and is evenly coiled throughout the interior of the tank, providing hot water rapidly and efficiently.

Raritan's water heaters use an ignition protected thermostat. Although it is factory set to 120°F, it is adjustable from 110° to 160°F and has a safety shut down limit of 190°F. All models and sizes have the plumbing connections on the same side to simplify installation. Hot and cold water connections are 3/4" male NPT (National Pipe Thread). Heat exchanger connections are 3/4" female NPT.

Benefits:

• Simple installation - retrofits to most on-board pressure systems
• Proven long-life design
• Withstands the rigors of the marine environment
• Glass-lined steel tank is more durable than stainless steel
• Attractive polymer jacket resists corrosion from dampness
• Ignition-protected, adjustable thermostat
• Round tanks are designed to withstand more pressure than square tanks
• Glass-lined steel tank for long life and high efficiency
• Environmentally friendly CFC-free foam insulation
• Replaceable magnesium anode to protect tank and neutralize acids in the water
• The tank is covered by a five-year Limited Warranty
• Each unit is assembled by hand, individually tested and backed by Raritan's two-year Limited Warranty and legendary technical support team

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Gallons: 12
• Heat Exchanger: Yes
• Volts: 120v
• Box Dimensions: 21"H x 22"W x 23"L WT: 58 lbs
• UPC: 085462001550

Trident Marine 1-1/2" x 50 Coil Premium Marine Sanitation Hose - White w/Green Stripe [102-1126]

1-1/2" x 50' Coil - Premium Marine Sanitation Hose - White with Green Stripe

Trident Premium Sanitation Hose resistant to odor permeation. Simply the BEST solution for marine environments, built with EPDM rubber to ensure the overall performance and resistance to odor permeation that you would expect in a sanitation hose.

Features:

• Resistance to Odor Permeation and winterizing with antifreeze
• With wire helix between 2 ply reinforcement this hose has excellent bend radius, flexibility, and fitting acceptance and retention
• This makes for easy installations with no heatgun or lubricant necessary
• 10 Year Warranty

Application:

• Premium Sanitation Hose for all head & holding tank connections
• NOT for potable water

Construction:

• Tube & Cover: EDPM/SBR Rubber
• Color: White with Green Stripe
• Reinforcement: Polyester reinforcement + spring steel wire helix
• Temperature Range: -20F-220°F (-29°C-104°C)
• Length: 50’ (15m)

Specifications:

• Inner Diameter: (inch) 1-1/2" / (mm) 38.1
• Outer Diameter: (inch) 2 / (mm) 50.8
• Working Pressure: (Psi) 60 / (bar) 4.1
• Weight: (Lb./50ft.) 44 / (Kg/m) 19.9
• Bend Radius: (inch) 3" / (mm) 76.2

*Burst Pressure is 4 x Working Pressure

Specifications:

• Length (Feet): 50'
• ID Diameter (inches): 1-1/2"
• Box Dimensions: 5"H x 26"W x 26"L WT: 37.7 lbs
• UPC: 704917015514

Quick Guide (pdf)

Whale Seaward 6 Gallon Hot Water Heater - Stainless Steel - 120V - 1500W [S700E]

Seaward 6 Gallon Hot Water Heater - Stainless Steel - 120V - 1500W

Whale Electric Water Heaters includes model with the very latest technology. All heaters are manufactured from the highest quality materials and designed to specifically withstand harsh marine conditions.

Water Heaters with a Stainless Steel cover offer high levels of corrosion resistance with a modern stainless steel finish. These heaters are a bit lighter than those wearing the galvanized outer cover and heavier than the epoxy coated versions.

Features and Benefits:

• Horizontal Mounting only
• Robust Manufacturing
• Hold down brackets welded to inner tank
• Safety controls
• Integrated pressure relief valve
• Temperature and pressure drain tube included
• Magnesium anodes available separately
• Recommended to prevent corrosion and ensure a longer Water Heater life
• Sturdy, robust exteriors
• Ignition protected

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Gallons: 6
• Heat Exchanger: No
• Volts: 120v
• Box Dimensions: 14"H x 14"W x 22"L WT: 23.6 lbs
• UPC: 766478948267

Brochure (pdf)

Raritan SANI/FLEX 1.5" Odor Shield Hose - 50' [SFH50]

SANI/FLEX 1.5" Odor Shield Hose - 50'

Highest quality marine sanitation hose. Butyl rubber construction has the lowest odor permeation level of any rubber or PVC material hoses. Extremely flexible for easy installation with a low bend radius of up to two times its diameter.

Features:

• Impermeability - Special butyl white rubber compound tube odor-free
• Flexibility - Allows tight bending radius making any installation easy
• Reinforcement - Double steel wire Helix with high-strength synthetic textile yarn
• Cover - White – abrasion, ozone, seawater resistant rubber
• Surface - Smooth fabric finished – antibacterial vanilla scented
• Interior - Smooth walled – no ridges – easily fits over fittings
• Warranty - 10-year guarantee against odor permeation

Specifications:

• ID: 1-1/2"
• OD: 1-7/8"
• Weight: 0.6lbs/ft.
• MAX Pressure: 105 PSI
• Burst Pressure: 315 PSI
• MAX Vacuum: 13.5 PSI
• Bend Radius: 3.15"

Quick Guide (pdf)
Brochure (pdf)
