Marine Navigation & Instruments - Radars

SI-TEX T-2041 Professional Dual Range Radar w/4kW 25" Dome - 10.4" Color TFT LCD Display [T-2041A]

Ships Direct From Manufacturer

T-2041 Professional Dual Range Radar with 4kW 25" Dome - 10.4" Color TFT LCD Display

With advanced radar features, up to 12kW power, and a large display, this professional dual-range radar is ideal for commercial and larger recreational vessels.

Features:

• Dual-Speed antenna with 48-rpm capability for high-speed/river operations
• Split-screen display of long- and short-range targets simultaneously
• True-Trail Function identifies moving targets
• Features include Interference Rejection, Target Expansion, Parallel Index, True/Relative Bearing
• Standard AIS Interface module capable of tracking 200 targets
• Optional 50-target Automatic Tracking Aid (ATA)

Specifications:

• Power - Output: 4kw
• Range - Max (Miles): 36nm
• Screen Size: 10.4"
• Box Dimensions: 24"H x 28"W x 28"L WT: 62 lbs

Owner's Manual (pdf)

Furuno TZtouch Radar Power Supply f/DRS2D & DRS4D [PSU017]

PSU017

The PSU017 is an external power supply designed to work with the DRS2D and DRS4D Dome Radar Sensors when interfaced with and NavNet TZtouch MFD.

Standard Features:

• Power supply for DRS2D and DRS4D Dome Radar Sensors

• Includes a pre-connected 3M power cable to connect directly to ship's main

• 12VDC or 24VDC input voltage and 48VDC DRS output voltage

• Cast Aluminum Housing

• Legendary Furuno power supply performance and reliability

• Dimensions: 9" h x 7.5" w x 3" d Weight with cable: 5lbs

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Quick Guide (pdf)
Owner's Manual (pdf)

Furuno NN3D Power Supply f/25W Radar [PSU013]

Ships Direct From Manufacturer

NN3D Power Supply for 25W Radars

The PSU013 Power Supply is required for all DRS25A installations and is included iwth the DRS25A.

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Furuno Power Supply f/NavNet 3D [PSU012]

Power Supply for NavNet 3D and TZtouch

The PSU012 Power Supply is required for DRS4A and DRS6A with MFD8, DRS12A with MFD8 or MFD12. The PSU012 Power Supply is required for DRS2D, DRS4D, DRS4A, DRS6A and DRS12A with TZT9 or TZT14.

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Furuno Power Supply f/1964C [PSU008]

Ships Direct From Manufacturer

Power Supply

Furuno's power supply is used specifically for Furuno's 1964C.

Features:

• 25kW

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Power - Output: 25kW
• Box Dimensions: 10"H x 14"W x 16"L WT: 16 lbs
• UPC: 611679295996

Furuno ARP11 10-Target Auto Plotter [ARP11]

ARP11 10-Target Auto Plotter

The ARP11 is a 10-target auto plotter designed for use with NavNet and NavNet vx2, as well as the FR8002 Radar series.

The ARP automatically tracks automatically or manually acquired radar targets and calculates their courses and speeds, indicating them by vectors. Since the data generated by the auto plotter are based on what radar targets are selected, the radar must always be optimally tuned for use with the ARP to ensure required targets will not be lost or unwanted targets such as sea returns and noise will not be acquired and tracked.

The plotting accuracy and response of this ARP meets IMO standards. Tracking accuracy is affected by the following:

• Tracking accuracy is affected by course change. One to two minutes is required to restore vectors to full accuracy after an abrupt course change. (The actual amount depends on gyrocompass specifications.)

• The amount of tracking delay is inversely proportional to the relative speed of the target. Delay is on the order of 15-30 seconds for high relative speed; 30-60 seconds for low relative speed.

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Simrad HALO 300X Radar Pedestal Only - 130W [000-15766-001]

Simrad's HALO 300X 130W Pulse Compression Radar: Pedestal Only.

Simrad's sleek and aerodynamic HALO 3000 Open Array Radar Pedestal combines with 3, 4 and 6-foot arrays to deliver easy to interpret radar images.

Features:

• Compatible with Simrad HALO 3000 130W Pulse Compression Radars
• Low profile allows for greater flexibility of boat architecture and more adaptable installation options
• High speed 48 RPM rotational speed allows for better tracking of fast targets
• Power and ethernet cable length varies across available models

Specifications:

• Applications: Simrad HALO 3000 130W Pulse Compression Radar
• Nominal supply voltage: 12 or 24 VDC
• Peak power output: 130W
• Rotation speed: 16 to 48 RPM depending on operating mode
• Height: 429 mm (16.88") with antenna mounted
• Weight: 44.8 lbs (20.3 kg)

8.5" Color LCD Radar with 4kW Output - 1/16-36nm Range - 25" Radome

SI-TEX's T-941 Radars feature sophisticated Hyper-Digital Processing™ (HDP) Technology for real-time presentation and superior target discrimination.

Features:

• It virtually eliminates unwanted noise to provide a clearer detailed image of targets and enhances the detection of smaller targets
• Radome: 4kW, 36NM, 25" Display
  • Brilliant 8.4" color LCD daylight viewable display
  • 480 x 640-pixel resolution and anti-reflective glare coating for outstanding viewing
  • True-color radar feature displays echoes in different colors depending on signal strength
  • The real-time presentation offers smooth movement as bearing changes
  • The T-941 has two-speed antenna rotation for tracking of quick-moving, close-in targets:
    • 48 RPM
    • 24 RPM (Requires 24 Volt DC input)
  • Selectable range scales from 1/16 NM
  • Warning Zone alerts you to "incoming" and "departing" targets breaking your preset guard zone
  • Automatic hands-off tuning maintains maximum sensitivity at all times with manual override for the experienced use
  • RGB output for connecting (2) optional external monitors
  • Easy access to all system functions with simply arranged keypad, programmable function keys, comprehensive menus and dedicated rotary knobs for instant control of Gain and STC
  • Built-in flush mounting system makes installation easy
  • All this advanced radar technology is housed in a sleek, waterproof (IPX5 rating) case design that can be mounted almost anywhere
  • Dual Range Radar function lets you view split-screen displays of both long and short-range targets simultaneously
    • Monitor a nearby buoy and a far off island at the same time
  • True Trail function clearly identifies moving targets from stationary targets
  • The display shows the exact movement of other vessels like drawing tails, while land and buoys are shown as stationary objects even while your vessel is moving
  • Accepts CCD camera input, to display split-screen Radar and Camera
    • Allows you to monitor important areas of your vessel while shill keeping watch of your surroundings
  • Optional ATA (Automatic Tracking Aid) allows you to tracks up to 50 user designated targets
  • Designate the target and the radar will automatically provide the target distance, speed, bearing, course, and closest point of approach on all user targets selected.
  • Optional AIS interface displays information on up to (100) AIS targets including the vessel's MMSI number, name, course, and speed of each vessel with an AIS transmitter
    • This information is sent continuously and is useful in navigating, traffic monitoring, and collision prevention

Specifications:

Antenna Unit:

• Scanner 25" Radome
• Peak Power Output 4kW
• Output Frequency 9410 + 30MHz
• Beam Width:
• Horizontal 3.9°
• Vertical 25°
• Rotation 24 or 48 rpm (48 rpm; 24V DC or more
• Pulse Width .08, 0.15, 0.3, 0.5, 1 use
• IF Frequency 60 MHz
• Range Accuracy Better than 8m
• Min. Detecting Distance: Within 25m

Display Unit:

• Display Size/Type 8.4" TFT Color LCD (480 x 640 pixels)
• Off Centering Max 66%
• Display Modes Heads up, North up*, Course up* WPT up**, True motion*
• Indication System PPI, PPI/PPI, PPI/NAV
• Range Scales NM 1/16, 1/8, 1/4, 1/2, 3/4, 1, 1.5, 2, 3, 4, 6, 7, 12, 16, 24, 32, 48 (T -- PNEW to 24,T -- 941 to 32, T -- 940 to 48)
• Range Rings NM 1/32, 1/16, 1/8, 1/4, 1/2, 3/4, 1/1.5, 2, 3, 4, 6, 8 12
• Bearing Accuracy Better than + 1°
• Video Level 8 colors
• Distant Unit (VRM unit) NM, SM, KM
• Alarms Entry or Breakaway (In and Out)
• Other Functions Interference rejection, Target expansion, VRM, EBL, Parallel index, Course position (Lat/Lon), Bearing (true/relative), Trail*, RGB Monitor output, Slave display monitor input/output, External buzzer. Accepts CCD camera input
• AIS Interface Option (100 targets)
• ATA Option (Auto/Manual, 50 targets)
• Input Data Format BEC, BWC, BWR, DPT, DBT, GGA, GLL, GNS, HDG, HDM, HDT, MTW, MWD, MWV, RMA, RMB, RMC, VHW, VTG, XTE
• Output Data Format TTM, TLL
• Power Requirements 10.8 - 31.2 Volt DC
• Power Consumption 55 Watt
• Water Protection
  • Display: IPX 5
  • Antenna CFR 46 IPX

What's In The Box?

• Display Unit MRD-103 with hardcover
• Connecting Cable 242J158055A -10 M with 2 connectors
• DC Power Cable CW265-2M 2m
• CCD Camera Cable CW-405-0.3M
• Operation manual, Quick reference
• Fuse (8A)

Specifications:

• Array Size (Inches): 25"
• Power - Output: 4kW
• Range - Max (Miles): 36nm
• Box Dimensions: 9"H x 11"W x 14"L WT: 46.25 lbs
