Lighting

Ethernet Communications Bridge & Multi-Zone Controller Kit

The Shadow-Caster MFD ( Multi-Function Display) Lighting Controller gives you full control of up to 6 independent zones of lighting on your vessel using your touchscreen MFD. Easily switch colors, adjust brightness, or synchronize lights with music. Set up scenes and deploy multiple changes to your zones all with one touch. Save your favorite settings and recall them later. Compatible with a wide range of MFD models from a range of manufactures including Garmin, Simrad, Lowrance, and B and G, Raymarine, and Furuno.

The SCM-MFD-LC is a kit that comes with two Shadow-Caster products. The Multi-Zone Lighting Controller ( SCM-ZC-SA) and the MFD Ethernet Communication Bridge ( SCM-MFD-Bridge). Allows a user to easily control all of the Shadow-Caster and Standard RGB lighting on their vessel. Designed to comply with an emerging NMEA lighting standard, the controller is designed to work on a CAN or NMEA2000 type network, through the use of Shadow-NET protocol CAN ( Control Area Network) Commands.

Features:

• Control Up to 6 Zones of Standard 4 or 5 wire RGB or Shadow-Caster Lights
• Quickly Adjust and Change Color and Brightness of Connected Lights
• Control Multiple Configurations of Color-Changing Patterns and Modes
• Includes 3.5 mm Audio Input for easy Music Synchronization

Phoenix XL Pod 7" LED Light

The Phoenix XL 7" light pod features over 14,000 lumens and five selectable color modes, allowing drivers to instantly switch between Cool White, Natural, Full Power, Warm, and Amber at the push of a button. No stopping and no leaving the cab. Designed for UTVs, overland rigs, and trail-ready vehicles, the Phoenix lineup offers three selectable Power Modes to optimize a vehicle's power system. Three interchangeable Lens Options, Spot, Drive, and Combo, provide precise beam customization to cover every area with purpose-built performance and RIGID-tough durability.

Features:

• Peak Performance: The Phoenix XL 7" light pod features over 14,000 Lumens.
• Amber to White: Switch Between 5 color modes, allowing drivers to instantly switch between Cool White, Natural, Full Power, Warm, and Amber at the push of a button. No stopping and no leaving the cab.
• 3 Selectable Power Modes: The Phoenix lineup offers three selectable Power Modes to optimize a vehicle's power system with a magnet switch.
• Swappable Lens: Three interchangeable Lens Options, Spot, Drive, and Combo, provide precise beam customization to cover every area with purpose-built performance and RIGID touch durability. *Drive and Combo Lens sold separately.
• Cast Aluminum Housing: To withstand the most brutal off-road conditions.
• Deutsch Connector: For easy installation.
• Protective Bezel: Cast aluminum bezel designed for lens protection and aerodynamics.
• Fortified Against The Elements: IP68+ related - sealed from water and dust.
• Connectable Mounting Solution: Designed for modular light bar applications.

Specifications:

• Size: 7"
• Light Shape: POD
• Mount Type: SURFACE MOUNT
• Beam Category: SPOT
• Voltage Range: 9V - 36V
• Raw Lumens: 14213
• Watts: 191
• Lux@10m: 2216
• Beam Distance @ 1 LUX: 471
• Beam Distance @ .25 LUX: 941
• Peak Beam Intensity (cd): 221579
• Horizontal Beam Angle: 20.0
• Vertical Beam Angle: 18.8
• Dimensions: 6.65" H x 6.8" W x 4.64" D, Weight 6.1 lbs
• HARNESS IS SOLD SEPARATELY
• ADDITIONAL SWAPPABLE LENS SOLD SEPARATELY

What's In The Box?

• Light
• Stainless Steel U-Shape Bracket
• Mounting Hardware
• Deutsch Connector
• 1 Spot Lens

Lopolight Series 301-006 - Stern Light - 2NM - Vertical Mount - White - Silver Housing  [301-006]

Series 301-006 - Stern Light - 2NM - Vertical Mount - White - Silver Housing

Lopolight started out back in 2004, offering many solutions and neat combinations for all size boats and yachts. The tradition continues.

Lopolight offers a full range of navigation lights dedicated for boats and yachts, resulting in an elegant,  compact and precise solution with good value for money.

Features:

• Single Light - Stern

Technical Specifications:

• Visibility - 2NM
• Vessel size - Up to 164' (Up to 50M)
• Operating Voltage - 10 - 32 VDC
• Number of LED Bulbs - 1
• Light Color - White
• Mounting - Vertical
• Materials - Anodized aluminum
• Connection - 8.2' (2.5M) cable
• IP rating - IP68
• Weight - 14.81oz

Certifications:

• U.S.C.G.
• EN14744
• COLREG72

In the Box:

• Navigation light w/8.2' (2.5M) cable
• Mounting hardware
• Installation guide

*Sold as an Individual

Specifications:

• Housing: Silver
• Lens Color: White
• Visible Range (Miles): 2NM
• Voltage - Input Range (Volts): 10 - 32
• LED: Yes
• Box Dimensions: 3"H x 6"W x 8"L WT: 0.95 lbs
• UPC: 879343009106

Quick Guide (pdf)
Brochure (pdf)

SCR-24 Bronze Underwater Light - 24 LEDs - Full Color Changing

The SCR series underwater LED lights are designed to be marine vessel hull mounted for continuous submersion in sea water. These models off a great value and small 4" diameter to fit many locations.  Multiple brightness options are available as well as single or multi-color.

High Intensity
Shadow-Caster underwater LED lights are designed to deliver the most intense optical output. Our unique design allows us to produce maximum light output and maximum LED life (over 40,000 hours).

Robust Design
With Shadow-Caster underwater LED lights, there’s no additional external components to install. Just connect the cable (submersible to 20 feet). All the necessary electronics are integrated into the housing and resistant to vibration and the elements.

Surface Mounted
Our lighting solutions feature a low profile design that requires no alteration to the main hull

Wide Input Voltage Range
Shadow-Caster’s underwater LED lights have an input range of 10 to 30 volts and work equally well on sets of 12 or 24 volts.

Surge and Reverse Polarity Protection
Our lighting systems have an innovative protection system that automatically disconnects the input entry when excessive voltage or reverse polarity is detected.

Thermal Protection
Our unique thermal protection features a control system that detects internal temperature and adjusts energy production down to avoid damage.

Features:

• 90 Watts (7.5 amps @12 volts)
• 4 “ Outside Diameter
• Bronze Housing
• Scratch-Resistant Glass Lens
• Surge and Reverse Polarity Protection
• Thermal Throttling ( C ) Above Water Protection
• Shadow-Net Enabled
• Includes 10’ Submersible Cord & Install Diagram
• 10-40 Volts input
• 2- Year Warranty
• Made in the USA

WARNING: This product can expose you to chemicals including Urethane which is known to the State of California to cause cancer or other reproductive harm, and LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Mounting Style: Surface
• Color: Full Color RGBW
• Material: Bronze
• Box Dimensions: 6"H x 6"W x 6"L WT: 2.2 lbs
• UPC: 8557260056060

SeaBlaze X3 LED Underwater Light - Spectrum

The SeaBlazeX3 represents the next evolution in surface-mount underwater lighting. Built on the proven legacy of our top-selling SeaBlaze Series, the X3 leverages decades of experience, innovation, and real-world marine performance to deliver our most advanced surface-mount light to date.

Utilizing the latest technology, SeaBlazeX3 achieves exceptional performance and efficiency - producing an impressive 8,000 darkness-piercing lumens while maintaining power consumption comparable to the outgoing SeaBlazeX2. But the performance is only part of the story. SeaBlazeX3 is the first Lumitec light to feature DryLock™ technology - a proprietary system that combines our advanced thermal management, leak protection, and moisture prevention technologies. Together, these innovations are engineered to deliver unmatched reliability and long-term protection in the harshest marine environments.

SeaBlazeX3 is available in a full-color spectrum and dual-color white/blue and carries a 5-year warranty. Poco system-compatible and IP69-rated X3 is designed to raise the bar on durability in surface-mount underwater lighting.

Specifications:

• 12v DC Amps: 5.5A
• 24v DC Amps: 2.5A
• Correlated Corrected Temperature (CCT): 6500
• CE Certified: Yes
• Color Match Commitment (CM): No
• Color Output: RGBW Spectrum
• Color Rendering Index (CRI): 70+
• Depth: 0.85 in (2.15 cm)
• Diameter: 3.94 in (8.86 cm)
• Finish / Housing: Bronze
• IP Rating: 68
• Lumens: 8000
• Mounting Hole: 0.5"
• Op. Temp F/C: F/C-31/35 to + 131/55
• PLI Enabled: Yes
• Related Watts: 65W
• Third Party Dimmer Compatibility (3PD): No
• Timed Toggled Protocol (TTP): Yes
• UL Certified: No
• Voltage: 10-30 vDC

360-Degree Anchor Light - 2NM - Black Housing with FB Base

This black 360-degree anchor light is horizontally mounted and has a two-nautical-mile range. The FB base centers the wiring for antenna-type pole mountings. The base provides a screw-down onto the deck solution as well as a from-below mounting. Essentially, the base provides a sleeker, reduced profile.

Features:

• Black anodized aluminum housing
• 0.75m cable is included

Specifications:

• Approved To: COLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR
• Mounting: Horizontal
• EAN: 5704438042797
• Min. Feed Wire Gauge: 0.5mm² AWG22
• Light Color: White
• Visibility: 2NM
• Included In the Package: 1 Navigation light, pre-cabled with 0.75 meter shielded marine grade cable and installation guide
• Materials: Black anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
• IP rating: IP68
• Connection: 0.75m cable
• Current Consumption (mA @ 24VDC): 110
• Current Consumption (mA @ 12VDC): 167
• Dimensions Metric: Ø92.5mm x 36mm
• Dimensions Imperial: Ø3.6" x 1.4"
• Operating Temperature: -25 degrees C to 55 degrees C
• Operating Voltage: 10-32VDC
• Power Draw (W): 2
• Vessel Size: Under 12 meters, 12-20 meters, and 20-50 meters

Specifications:

• Housing: Black
• Visible Range (Miles): 2NM
• Voltage - Input Range (Volts): 10 - 32
• Box Dimensions: 4"H x 4"W x 4"L WT: 1.2 lbs
• UPC: 879343042929

Series 301-011KL - Masthead Light - 5NM - Horizontal Mount - White - Silver Housing

Lopolight started out back in 2004, offering many solutions and neat combinations for all-size boats and yachts. The tradition continues.

Lopolight offers a full range of navigation lights dedicated for boats and yachts, resulting in an elegant,  compact, and precise solution with good value for money.

Features:

• Single light - Masthead
• Extended CSCD (400-034) base

Technical Specifications:

• Visibility - 5NM
• Vessel size - 65.6' to 164' (20 - 50M)
• Operating Voltage - 10 - 32 VDC
• Number of LED Bulbs - 1
• Light Color - White
• Mounting - Horizontal
• Materials -  Anodized aluminum
• Connection - Plug connector
• IP rating - IP68
• Weight - 15.17oz (.43kg)

Certifications:

• U.S.C.G.
• EN14744
• COLREG72

In the Box:

• Navigation light
• Connector
• Mounting hardware
• Installation guide

*Sold as an Individual

Specifications:

• Voltage - Input Range (Volts): 10 - 32
• Visible Range (Miles): 5NM
• Lens Color: White
• LED: Yes
• Housing: Silver
• Box Dimensions: 4"H x 4"W x 8"L WT: 2.5 lbs
• UPC: 879343011765

Blue/White Color Changing Underwater Light - 16 LEDs - Bronze

The SCR-16 is a 16 LED round light. Presenting exceptional brightness in a flood pattern, the SCR-16 is built into durable bronze housing, complete with a scratch-resistant glass lens. The Shadow-Caster SCR is a beautiful compliment to any vessel.

High Intensity
Shadow-Caster underwater LED lights are designed to deliver the most intense optical output. Our unique design allows us to produce maximum light output and maximum LED life (over 40,000 hours).

Robust Design
With Shadow-Caster underwater LED lights, there’s no additional external components to install. Just connect the cable (submersible to 20 feet). All the necessary electronics are integrated into the housing and resistant to vibration and the elements.

Surface Mounted
Our lighting solutions feature a low profile design that requires no alteration to the main hull

Wide Input Voltage Range
Shadow-Caster’s underwater LED lights have an input range of 10 to 30 volts and work equally well on sets of 12 or 24 volts.

Surge and Reverse Polarity Protection
Our lighting systems have an innovative protection system that automatically disconnects the input entry when excessive voltage or reverse polarity is detected.

Thermal Protection
Our unique thermal protection features a control system that detects internal temperature and adjusts energy production down to avoid damage.

Features:

• 60 Watts (5 amps @ 12 volts)
• 4 “ Outside Diameter
• Bronze Housing
• Scratch-Resistant Glass Lens
• Surge and Reverse Polarity Protection
• Thermal Throttling ( C ) Above Water Protection
• Includes 10’ Submersible Cord & Install Diagram
• 10-40 Volts input
• 2- Year Warranty
• Made in the USA

WARNING: This product can expose you to chemicals including Urethane which is known to the State of California to cause cancer or other reproductive harm, and LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Mounting Style: Surface
• Color: Full Color RGBW
• Material: Bronze
• Box Dimensions: 6"H x 6"W x 6"L WT: 2.4 lbs
• UPC: 8557260056442
