Lighting - Search Lights

ACR RCL-200 White Wireless LED Searchlight w/URP-103 Wired Point Pad URH-103 Wireless Handheld Remote [1965]

ACR Electronics

ACR RCL-200 White Wireless LED Searchlight w/URP-103 Wired Point Pad URH-103 Wireless Handheld Remote [1965]

~~$4,285.95~~$3,895.95

RCL-200 White Wireless LED Searchlight with URP-103 Wired Point Pad & URH-103 Wireless Handheld Remote

The RCL-200 LED marine searchlight combines sleek design with uncompromising durability to meet the demands of today’s boaters. Engineered with a rugged die-cast aluminum housing, this searchlight is built to withstand harsh marine environments while maintaining a stylish, contemporary look that complements any vessel.

Powered by 12 high-intensity LEDs, the RCL-200 LED produces a brilliant beam of 720,000 candelas, ensuring maximum visibility and safety during night navigation or search-and-rescue operations. With multi-voltage support (DC 12V–24V), it offers installation flexibility across a wide range of boats.

Designed with convenience and versatility in mind, the RCL-200 LED features advanced control functions, including the ability to return to home position on command and operate two searchlights from one station—or two searchlights from two stations. Whether upgrading an existing system or outfitting a new vessel, this searchlight delivers the reliability, performance, and style you expect on the water.

Features:

720,000 Peak Candela 12 High Flux 60W LEDs
Wireless Handheld Remote
360 Degree Rotation 55 Degree Tilt
Energy-Efficient Low Amp Draw
Easy Installation 12-24V Power Only
LEDs: 50,000 Operating Hours
Includes URP-103 Wired Point Pad and URH-103 Wireless Handheld Remote

Specifications:

Material: Die-Cast Aluminum Housing
Weight: 16.5 lbs (7.5 kg)
Size: 12.77 x 10.13 x 10.11” (32.43 x 25.72 x 25.67 cm)
Operation: Wireless Handheld Remote and Wired Dash Mount Point Pad
Warranty: 1 Year
Elevation: Angle 55°
Beam Pattern / Angle: Spot
Peak Beam Candle Power: 720,000 Candela
Beam Max. Distance: 5,568 ft (1697 meters)
Rotation: 360°
Rotation / Elevation Speed: Fast 16° per second, slow 3° per second / Up: 18° per second / Down: 22° per second
Power Requirements: 12 to 24 V DC
Lamp: LED 60W (OSRAM x 12) / 50,000 hour life
IP Rating: IP66 (Housing) / IP68 (LED Module)

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

Bulb Watts: 60
Candela: 720,000
Candle Power: 720,000
LED: Yes
Voltage - Input Range (Volts): 12/24
Wireless: Yes
Box Dimensions: 17"H x 17"W x 18"L WT: 29 lbs

Brochure (pdf)

ACR Electronics

ACR RCL-50 LED Searchlight - 12/24V - Black [1961]

~~$1,789.37~~$1,626.70

RCL-50 LED Searchlight - 12/24V - Black

Designed for small-to-mid-size pleasure crafts and small commercial vessels, this rugged searchlight boasts a new 6 LED lamp with over 100,000-candela power. Built for the rough and tough marine environment, the new RCL-50 utilizes the same proven die-cast aluminum housing with all new internal mechanical controls to power and rotate the ultra-bright LED lamp.

The RCL-50 LED’s traditionally sleek design makes it an attractive and cost-effective choice for sport yachts, yachts, sport fishers, workboats, and light commercial vessels. With more efficient LEDs, the RCL-50 LED has reduced power consumption demand by up to 50% on 12/24V vessels.

Features:

Ultra-bright, 6 LED Array
Rugged triple-primed and sealed, marine-grade aluminum housing
Exclusive XRCiZ™ feature rotates and moves light assembly every 30 days from activation to keep all bearing surfaces free of corrosion and all electrical contacts functional
Can be used in conjunction with up to 3 controllers
Simple installation

Technical Specifications:

Color - Black
Material - Die-cast aluminum (518)
Operation - Remote-controlled Point Pad™
Voltage Input - 12/24 VDC
Rotation - 360° continuous
Tilt - 40°
Light Pattern - Spot
Dimensions (H x W x D) - 8.4" x 6" x 8" (21.3 x 15.2 x 20 cm)
Dimensions (Footprint Diameter) - 4.75” (120.7 cm)
Weight - 7.72 lb (3.5 kg)

In the Box:

RCL-50 Searchlight (12 V)
URP-102 Point Pad™ remote
URC-102 Master controller
Instruction manual

*Sold as an Individual

WARNING: This product can expose you to chemicals including BISPHENOL A (BPA) which is known to the State of California to cause birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

Voltage - Input Range (Volts): 12/24v
LED: Yes
Candela: 100,000
Wireless: No
Box Dimensions: 12"H x 12"W x 12"L WT: 12.4 lbs
UPC: 791659019610

Owner's Manual (pdf)

ACR Electronics

ACR RCL-100 LED Searchlight Kit - 12/24V - White [1951]

~~$2,160.24~~$1,963.85

ACR RCL-100 LED Searchlight Kit - 12/24V - White

Not all searchlights are created equally. The LED version of our most popular RCL-100D searchlight provides high-intensity LED performance that pierces through nights and low lighting conditions with a blazing 220,000 candela. The RCL-100 LED’s traditionally sleek design makes it an attractive and cost-effective choice for sport yachts, mega-yachts, sport fishers, and light commercial vessels.

The die-cast aluminum case is triple-primed and painted with UV stabilizer to withstand years of exposure in the harsh marine environment. The light’s internal elevation mechanisms are fully enclosed and provide precise pitch control of the beam while staying protected. The LED bulbs are efficiently designed to provide over 40,000 operating hours. The light also includes our Exclusive XRCiZ™ feature that is pre-programmed and allows for the light to independently rotate every 30 days from activation to ensure all bearing surfaces are free of corrosion and all electrical contacts are functional.

This package also includes a URP-102 Point Pad™ controller and a URC-103 Master Controller. All this makes for a powerful searchlight that is easy to use from multiple control points.

Features:

Ultra-bright, 9 LED array generating over 220,000 peak candela
Efficient, long-life LEDs - 40,000 operating hours
Reduced power consumption
The controller has state-of-the-art electronics to protect the light from most power surges
Internal elevation mechanism for precise pitch control of the beam
Rugged triple-primed and sealed, marine-grade aluminum housing
Cababe of working with up to three remote Point Pad™ units
Exclusive XRCiZ™ feature rotates and moves the light assembly every 30 days from activation to keep all bearing surfaces free of corrosion and all electrical contacts functional

Technical Specifications:

Color - White
Material - 518 Die-cast aluminum
Operation - Dash Mount Point Pad™
Voltage Input - 12/24 VDC
Rotation - 360° continuous
Light Pattern - Spot
Light Distance - 4,501' (1,372 M)
Dimensions (H x W x D) - 8" x 9" x 8" (20.3 x 22.9 x 20.3 cm)
Dimensions (Footprint Diameter) - 4.75" (12.7 cm)
Weight - 7.2 lb (3.2 kg)

In the Box:

RCL-100 LED Searchlight (12/24 V)
Dash Mount Point Pad™ controller (URP-102)
Master controller (URC-103)
Instruction manual

*Sold as an Individual

WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:
