Trident Marine 2-1/2" x 50' Extra-Flex Corrugated Marine Wet Exhaust Hose [252F-2126]

Ships Direct From Manufacturer

2-1/2" x 50' Extra-Flex Corrugated Marine Wet Exhaust Hose

Trident Extra-Flex corrugated marine wet exhaust hose with EXTRA flexibility for easier installations on tight bends for longer connections. Thick tube and cover with wire helix between 2-ply reinforcement. Exceptional flexibility and bend radius. Resists heat, ozone, exhaust fumes, panting, and collapse. Exceeds (SAE J2006-R2, and ABYC & NMMA P-1 exhaust standards). Lloyd’s Registry Type Approved.

Corrugated Wet Exhaust and Water Marine Hose offers the best performance with an incredible bend radius and high-temperature EPDM Rubber compounds. This enables it to handle higher temperatures while providing longer life and durability than its competition. It exceeds SAE J2006-R2, ABYC, and NMMA P-1 exhaust standards and is Lloyd’s Registry Type Approved. Black High Temp EDPM Rubber 250°F (121°C) Max. continuous.

Features:

• Black High Temp EDPM Rubber 250°F (121°C) Max.
• Sizes: 1 1/2" to 8", 38mm to 203.2 mm
• Colors: Black with White stripe with yellow edges
• Packaging: 6.25' to 12.5' (1.9-3.8m) lengths, 50’ (15m) Coils

Specifications:

• ID Diameter (inches): 2-1/2"
• Length (Feet): 50'
• Box Dimensions: 5"H x 55"W x 55"L WT: 63 lbs
• UPC: 704917028248

Quick Guide (pdf)

Alternator - 240 AMP - 12V - 4” K6 Pulley with Isolated Ground

12-volt, 240 amp isolated ground alternator that is designed for external regulation. Also, has a 4" dual-foot saddle mount that is J180-style.

Features:

• 4″ J-180-Style mounting (typical for Caterpillar, Cummins, Detroit Diesel, and John Deere engines)

Specifications:

• Volts: 12V
• Amps: 240A
• Mount: Dual foot - 4"
• Pulley: K6 Serpentine
• Replaces: 97EHD-185-12-IG, 97EHD-265-12-IG

Specifications:

• Amperage: 240A
• Voltage: 12v

Trident Marine 3" x 50' Extra-Flex Corrugated Marine Wet Exhaust Hose [252F-3006]

Ships Direct From Manufacturer

3" x 50' Extra-Flex Corrugated Marine Wet Exhaust Hose

Trident Extra-Flex corrugated marine wet exhaust hose with EXTRA flexibility for easier installations on tight bends for longer connections. Thick tube and cover with wire helix between 2-ply reinforcement. Exceptional flexibility and bend radius. Resists heat, ozone, exhaust fumes, panting, and collapse. Exceeds (SAE J2006-R2, and ABYC & NMMA P-1 exhaust standards). Lloyd’s Registry Type Approved.

Corrugated Wet Exhaust and Water Marine Hose offers the best performance with an incredible bend radius and high-temperature EPDM Rubber compounds. This enables it to handle higher temperatures while providing longer life and durability than its competition. It exceeds SAE J2006-R2, ABYC, and NMMA P-1 exhaust standards and is Lloyd’s Registry Type Approved. Black High Temp EDPM Rubber 250°F (121°C) Max. continuous.

Features:

• Black High Temp EDPM Rubber 250°F (121°C) Max.
• Sizes: 1 1/2" to 8", 38mm to 203.2 mm
• Colors: Black with White stripe with yellow edges
• Packaging: 6.25' to 12.5' (1.9-3.8m) lengths, 50’ (15m) Coils

Specifications:

• ID Diameter (inches): 3"
• Length (Feet): 50'

Quick Guide (pdf)

Trident Marine 8" ID x 6' Long Silicone Marine Wet Exhaust  Water Hose - Blue [202V8001]

8" ID x 6' Long Silicone Marine Wet Exhaust & Water Hose - Blue

Trident Silicone Marine Wet Exhaust and Water-Coolant Hose is the ultimate in extra thick soft wall silicone quality with very high-temperature performance and extra long service life. Exceeds SAE J2006-R1, and ABYC & NMMA P-1 exhaust standards. #202V Glossy Blue “Very Hi Temp” has 4-6 ply polyester reinforcement and 350°F (177°C) Max. Used worldwide on premium boats, yachts, and special service vessels. It has become the super yacht standard.

Specifications:

• ID Diameter (inches): 8"
• Length (Feet): 6'
• Box Dimensions: 15"H x 15"W x 15"L WT: 24 lbs
• UPC: 704917010717

Quick Guide (pdf)

Alternator 250 AMP Kit 12V 3.15" Dual Foot Saddle Dual Vee Pulley Regulator & Temp Sensor

Kit Includes: XT-DF-250-DV Alternator, MC-618 Regulator, Temperature Sensors & Mounting Hardware

XT Series Alternator: 250A, 12V, Saddle Mount (Dual Foot), 3.15in, Dual Deep Vee Pulley, Case Ground

Hitachi-Style Mounting; Typical for Yanmar, Westerbeke, Lehman & Perkins-Sabre Engines

Replaces: AT-DF-MC-200-KIT, AT-DF-200-DV-KIT

Specifications:

• Amperage: 250A
• Voltage: 12v
• Box Dimensions: 11"H x 11"W x 14"L WT: 21 lbs
• UPC: 676205502252

Balmar Alternator 100 AMP 12V 3.15" Dual Foot Saddle J10 Pulley w/Isolated Ground [60-100-J10]

Alternator 100 AMP 12V 3.15" Dual Foot Saddle J10 Pulley with Isolated Ground

Alternator, 60 Series, 100A, 12V, Saddle Mount (Dual Foot), 3.15in, J10 AltMount Serpentine Pulley, Isolated Ground Hitachi-Style Mounting; Typical for Yanmar, Westerbeke, Lehman & Perkins-Sabre Engines

Replaces: 60-100-SR-IG

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

• Amperage: 100A
• Voltage: 12v
• Box Dimensions: 9"H x 9"W x 10"L WT: 12.7 lbs
• UPC: 676205500661

Brochure (pdf)

Balmar Alternator 120 AMP 12V 4" Dual Foot Saddle Dual Pulley w/Isolated Ground [604-120-DV]

Alternator 120 AMP 12V 4" Dual Foot Saddle Dual Pulley with Isolated Ground

Alternator, 604 Series, 120A, 12V, Saddle Mount (Dual Foot), 4in, Deep Dual Vee Pulley, Isolated Ground 4" J-180-Style Mounting;  Typical for Caterpillar, Cummins, Detroit Diesel & John Deere Engines

Replaces: 604-120-SR-IG

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

• Amperage: 120A
• Voltage: 12v
• Box Dimensions: 9"H x 9"W x 10"L WT: 13.65 lbs
• UPC: 676205131117

Brochure (pdf)

Alternator 250 AMP 12V 3.15" Dual Foot Saddle K6 Pulley

Alternator, XT Series, 250A, 12V, Spindle Mount (Single Foot), 3.15in, K6 Serpentine Pulley, Case Ground

Specifications:

• Amperage: 250A
• Voltage: 12v
• Box Dimensions: 9"H x 10"W x 10"L WT: 16 lbs
• UPC: 676205503501
