Alternator 170 AMP 12V 4" Dual Foot Saddle K6 Pulley

Balmar offers a wide range of alternator power upgrades designed specifically for marine industry applications. They install high-reliability bearings, robust rectifier diodes, and improved heat-sinking capabilities on all their alternators to ensure improved system reliability combined with increased charging power.

Features:

• 4" Dual-Foot K6 Serpentine Pulley
• 170A
• 12V
• Case Ground
• J-180 Mount; Typical for John Deere, Cummins, & Caterpillar Engines

This product may not be returned to the original point of purchase.  Please contact the manufacturer directly with any issues or concerns.

Specifications:

• Amperage: 170A
• Voltage: 12v
• Box Dimensions: 9"H x 9"W x 10"L WT: 15 lbs
• UPC: 676205503464

Alternator 1-2" Single Foot K6 Serpentine Pulley - 170A - 12V

Balmar offers a wide range of alternator power upgrades designed specifically for marine industry applications. Balmar installs high reliability bearings, robust rectifier diodes and improved heat-sinking capabilities on all our alternators to ensure improved system reliability combined with increased charging power.

Features:

• 1-2" Single Foot K6 Serpentine Pulley
• 170A
• 12V

Specifications:

• Voltage: 12v
• Amperage: 170A
• Box Dimensions: 9"H x 10"W x 10"L WT: 14.45 lbs
• UPC: 676205500852

Zeus A275L J180 4" Alternator with Isolated Ground, Terminal Block & Zeus High-Energy Alternator Regulator

Zeus A275L J180 4" Alternator with Isolated Ground & Terminal Block

The highest power output alternator in its size/class.

Features:

• Engineered for high energy production.
• Suitable for marine, RV, military, and commercial applications.
• Rapidly charges large battery banks.
• Coolest operating temperatures for increased performance.
• Heat-shedding coatings
• Rectifier located on housing exterior
• Dual cooling fans
• OEM components
• Optimized for performance at idle speeds.
• Reduces the need for a generator by creating additional power with your engine.
• Unleash peak performance with E-Coat/Cerakote, keeping the A275L cooler for sustained amperage output.
• Use the ARCO Zeus Bluetooth Alternator Regulator for maximum performance or lithium battery charging.
• SAE J1171 Certified.
• Models are available with internal/external voltage regulators.
• Proudly made in the U.S.A.

Technical Specifications:

• Voltage - 12V
• Field Type - P
• Rotor Poles - 16
• Stator Size - 138mm
• Frame Size - Large
• Weight - 14.9 lbs/6.7 kg
• Regulation - Internal/External (Internally regulated with adaptor for optional external regulation.)
• Output Voltage - 14.1v (Default)
• Finish - (Black) Cerakote or E-coating
• Cut-In RPM - 1,061 Alternator RPM
• Maximum Alt RPM - 19,000
• Battery Post - M8 Thread Post, Side Mount
• Standard Pulley - 49K6 (6-groove, 49mm)
• Pulley Mount - 17mm diameter shaft, 25mm long, threaded M17 x 1.5
• Pulley Hardware - M17 x 1.5 x 24mm nut, w/ 18mm ID x 29mm OD washer (Included)
• Diodes - 6 positive, 6 negative, 50A Rated, Avalanche
• Max Output (Cold, 9,000 RPM) - 311 Amps
• Sustained Cruising Output (Hot, 6,000 RPM) - 227 Amps
• Sustained Idle Output (Hot, 3,000 RPM) - 198 Amps
• Max Continuous Operating Temperature - 110°C / 230°F

Mounting Applications:

• Replaces most Volvo Penta alternators using a 4” J180 saddle-style mount

Zeus High-Energy Alternator Regulator

ARCO’s Zeus is the only high-energy external alternator regulator to feature Bluetooth and a native app (on IOS and Android) allowing for easy installation and configuration. With its intuitive interface, you can access information on your system that you never had before. This information will enable you to regulate your system and optimize your battery charge and alternator output, resulting in a safer experience while protecting your energy system investment.

Zeus is the only alternator regulator that can read 2 shunts at a time (the battery shunt and alternator shunt). This feature enables Zeus to react to inputs from the battery current/temperature and alternator current/temperature.

Through the ARCO Zeus application, you are in good hands. Your data is automatically logged and can be shared with your technician to troubleshoot your system remotely. You can even import your remote technician’s configurations.

Zeus optimizes battery charges for 12-48 volt systems. Whether you are using Lithium (LiFePo4) batteries or lead-acid Deep Cycle batteries, Zeus has you covered with its pre-set battery libraries and configurable menus to optimize your charging profiles. Zeus manages a complex set of inputs by giving you easy-to-understand options.

Zeus also takes into consideration the power of your engine and allows you to configure the alternator’s power take-off from the engine by managing the field, or duty. An advanced feature of Zeus is that it can turn your engine into a dedicated generator with the press of a button, whereby it focuses the alternator’s performance on the creation of energy to replenish your battery bank quickly.

Consistent with Zeus’ ease of use, Zeus is the only alternator regulator on the market that comes with alternator/battery harnesses and 2 thermistor harnesses, without an additional charge, saving users money and time from sourcing harnesses.

Features:

• Secure Bluetooth connection
• Harnesses, Thermistors, and NMEA 2000 kit included
• Monitors the state of charge
• Can turn your engine into a dedicated generator with generator mode
• Pre-set battery libraries
• Data logging and sharing
• CAN bus and NMEA 2000-integrated networks
• Compatible with all voltage systems (12- 48V)
• IP66 & IP67 rated
• 2-Year warranty

Technical Specifications:

• Enclosure dimensions without antenna - 8.2" x 5.9" x 2.4"
• Enclosure dimensions with antenna - 8.2" x 7.5" x 2.4"
• Weight - 1.7 lbs

In the Box:

• Zeus high-energy alternator regulator
• Battery wiring harness
• Alternator wiring harness
• 2 thermistors

ARCO Marine Premium Replacement Yamaha Outboard Starter - 13 Tooth [3433]

Premium Replacement Yamaha Outboard Starter - 13 Tooth

This outboard starter will fit Yamaha 2004-Up 150 HP, 4-Stroke, 2005-Up 250 HP, 4-Stroke, 2006-Up 225 HP, and 4-Stroke.

ARCO advises using a fully charged battery - A weak battery can damage the starter and starter solenoid. And to also clean all connections - A corroded connection creates resistance, lowering the amperage required for an efficient starting circuit.

Features:

• Dynamically tested and packaged for out-of-the-box performance
• Nickel-coated and/or epoxy-painted to reduce corrosion
• Sealed to minimize water intrusion
• Designed for long life and optimum performance
• Armatures are tested to withstand 50 times operating voltages (12 volts)

Warranty Information:

When properly installed, all ARCO products are warrantied against defects in materials and workmanship for 12 months for leisure use and 90 days for commercial or racing applications.

Add an extra year of warranty to your rotating electric ARCO product (Tilt/Trim Motors, Alternators, Outboard Starters, and Inboard Starters) when you register your product within 30 days of purchase. You can register your product by visiting arcomarine.com/product-registration

Replaces:

• HITACHI Outboard Starter S114-867
• HITACHI Outboard Starter S114-867A
• YAMAHA Outboard Starter 63P-81800-00
• YAMAHA Outboard Starter 6BR-81800-00
• YAMAHA Outboard Starter 6BR-81800-01

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Quick Guide (pdf)

Alternator 170 AMP Kit 12V 3.15" Dual Foot Saddle K6 Pulley Regulator & Temp Sensor

Kit Includes: XT-DF-170-K6 Alternator, MC-618 Regulator, Temperature Sensors & Mounting Hardware

XT Series Alternator: 170A, 12V, Saddle Mount (Dual Foot), 3.15in, K6 Serpentine Pulley, Case Ground

Hitachi-Style Mounting; Typical for Yanmar, Westerbeke, Lehman & Perkins-Sabre Engines

Replaces: AT-DF-MC-165-KIT, AT-DF-165-K6-KIT

Specifications:

• Amperage: 170A
• Voltage: 12v
• Box Dimensions: 10"H x 11"W x 14"L WT: 17.5 lbs
• UPC: 676205503594

Balmar Alternator 100 AMP Kit 12V 1-2" Single Foot Spindle Mount K6 Pulley Regulator  Temp Sensor [621-VUP-MC-100-K6]

Alternator 100 AMP Kit 12V 1-2" Single Foot Spindle Mount K6 Pulley Regulator & Temp Sensor

Kit Includes: 621-100-K6 Alternator, MC-618 Regulator, Temperature Sensors, Mounting Hardware

621-100-K6 Alternator: 100A, 12V, Spindle Mount (Single Foot), 1-2in, K6 Serpentine Pulley, Isolated Ground

1" Motorola-Style Mounting;  Typical for Westerbeke, Lehman, Hino & Pathfinder Engines
2" Delco-Style Mounting;  Typical for Volvo Penta (Gas & Diesel), John Deere, Perkins, Mercruiser, Pleasurecraft, Crusader, Indmar, Marine Power & other GM-based Engines

Replaces: 621-VUP-MC-100-SR-KIT

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

• Amperage: 100A
• Voltage: 12v
• Box Dimensions: 10"H x 11"W x 14"L WT: 9.25 lbs
• UPC: 676205750943

Brochure (pdf)

Alternator 170 AMP Kit 12V 3.15" Dual Foot Saddle J10 Pulley Regulator & Temp Sensor

Kit Includes: XT-DF-170-J10 Alternator, MC-618 Regulator, Temperature Sensors & Mounting Hardware

XT Series Alternator: 170A, 12V, Saddle Mount (Dual Foot), 3.15in, J10 AltMount Serpentine Pulley, Case Ground

Hitachi-Style Mounting; Typical for Yanmar, Westerbeke, Lehman & Perkins-Sabre Engines

Replaces: AT-DF-MC-165-KIT, AT-DF-165-J10-KIT

Specifications:

• Amperage: 170A
• Voltage: 12v
• Box Dimensions: 10"H x 11"W x 14"L WT: 17 lbs
• UPC: 676205503648

170 AMP Alternator Kit - 12V 4" Dual Foot Saddle Mount with K6 Pulley, Regulator & Temp Sensor

Balmar offers a wide range of alternator power upgrades designed specifically for marine industry applications. They install high-reliability bearings, robust rectifier diodes, and improved heat-sinking capabilities on all their alternators to ensure improved system reliability combined with increased charging power.

Kit Includes:

• XT-DF4-170-K6 Alternator, MC-618-H Regulator, Temperature Sensors & Mounting Hardware

Features:

• 4" Dual-Foot K6 Serpentine Pulley
• 170A
• 12V
• Case Ground
• J-180 Mount; Typical for John Deere, Cummins, & Caterpillar Engines

This product may not be returned to the original point of purchase.  Please contact the manufacturer directly with any issues or concerns.

Specifications:

• Amperage: 170A
• Voltage: 12v
• Box Dimensions: 11"H x 11"W x 14"L WT: 18.35 lbs
• UPC: 676205503471
