Electrical - Battery Chargers

Pro Series Dolphin Battery Charger - 24V, 100A, 230VAC - 50/60Hz

The Dolphin Series of battery chargers has always been recognized for its outstanding quality, which the manufacturer is proud to support with a 2-year warranty. Due to production on a wide scale, Dolphin is able to offer high-quality, truly international battery chargers at a reasonable price.

The Pro Range, which allows battery banks of up to 1000 amps to be charged, can be equipped with an optional touchview touchscreen. It provides an intuitive display of measurements as well as charging phases (boost, absorption, and float), the allocated available power, and possible operating faults. The Pro range is equipped with communication via CAN bus, which means it can be used professionally in all land and industrial energy management sectors.

Features:

• 24V-100A Dolphin Pro (230 VAC 50/60 Hz input voltage only)
• All Dolphin Battery Chargers and accessories are CE-marked and manufactured to UL and ABYC specifications
• The Pro Touch Range features a built-in TouchView remote in place of the standard display panel on the Pro chargers
• The Touchview control panel gives the user more information and control of the charger functions
• LED Display for programming and monitoring functions
• Temperature sensor for battery compensation
• Switch mode technology and a three-stage charging design with a power supply
• Modern, lightweight, and compact design with white aluminum powder-coated casing
• Universal AC input with automatic voltage switching 115/230 VAC 50/60 Hz (24V-80A, 24V-100A, and 24V-150A are 230VAC 50/60 Hz ONLY)
• 4 screw simple install with easy access removable panel
• ISO 9002-certified manufacturing plant

Three-Stage Charging Curve

Bulk Stage: A high current is sent to the battery until it reaches approximately 80% of its full charge.

Absorption Stage: The voltage level is maintained and the current is reduced until the battery is 100% charged.

Float Stage: Voltage and current are reduced to maintain the battery. Float gives what the battery requires.

Specifications:

• Charger Input - Voltage: 230v
• Charger Output - Amps: 100a
• Charger Output Voltage: 24v
• Portable: No
• Box Dimensions: 11"H x 16"W x 19"L WT: 27.7 lbs
• UPC: 786142995045

ProTournamentelite 360 Battery Charger - 3 Bank - Global/CZone

With all of the innovation, performance, and features of the new ProTournamentelite series3 ProMariner has engineered the offering to include three high-power connected global models with ProMariner's integrated Czone communication feature, which provides: battery chemistry, charge mode, real-time charging voltage, amperage, and fault status.

Features:

• IP67-sealed waterproof design
• Line of sight, charge status, AC glow plug
• Selectable Turbo Charge Mode
• Forced power flow cooling
• 4 digitally selectable charge profiles
• Dual-mode battery status monitor
• Distributed-On-Demand Technology™

Specifications:

• Volts: 12/24/36
• Total Amps: 36
• Battery Banks: 3
• Cable Length: 6 ft.
• Size (inch): 9.3" x 4.2" x 14.7
• Weight: 16.1 pounds
• AC In/Max Amps: 100-240 VAC / 8 A

Specifications:

• Charging Banks: 3
• Box Dimensions: 9"H x 11"W x 18"L WT: 18.5 lbs
• UPC: 031669553637

ProTournamentelite 500 Battery Charger - 5 Bank - Global/CZone

With all of the innovation, performance, and features of the new ProTournamentelite series3 ProMariner has engineered the offering to include three high-power connected global models with ProMariner's integrated Czone communication feature, which provides: battery chemistry, charge mode, real-time charging voltage, amperage, and fault status.

Features:

• IP67-sealed waterproof design
• Line of sight, charge status, AC glow plug
• Selectable Turbo Charge Mode
• Forced power flow cooling
• 4 digitally selectable charge profiles
• Dual-mode battery status monitor
• Distributed-On-Demand Technology™

Specifications:

• Volts: 12/24/36/48 + Eng
• Total Amps: 50
• Battery Banks: 5
• Cable Length: 6 ft.
• Size (inch): 9.3" x 4.2" x 16.6"
• Weight: 18.0 pounds
• AC In/Max Amps: 100-240 VAC/10 A

Specifications:

• Charging Banks: 5
• Box Dimensions: 9"H x 10"W x 20"L WT: 20.6 lbs
• UPC: 031669555051

Phoenix Smart IP43 Charger 24/25 (3) 120-240VAC Requires 5-15P Mains Cord

With boat owners in mind, this adaptive 5-step charger can provide either 30A or 50A of charge to each of the three battery banks. Or the Phoenix 1+1 model provides 3A to the starter battery, the rest to the ‘house’ bank. 24V models are available with a 16A/25A charge. Bluetooth enabled, you can monitor the charger and set alarms straight from your phone.

Features:

• Bluetooth Smart built-in: The wireless solution to set up, monitor, update and synchronize Phoenix Smart IP43 Chargers.
• Phoenix Smart (1+1): two outputs to charge 2 battery banks: The second output, limited to approximately 4A and with a slightly lower output voltage, is intended to top up a starter battery.
• Phoenix Smart (3): three full current outputs to charge 3 battery banks: Each output can supply the full rated output current. But the total of the 3 outputs combined can never exceed the current rating of the charger.
• Automatic voltage compensation: The charger compensates for voltage drop over the DC cabling by slightly increasing output voltage when the DC current increases.
• Adaptive 6-stage charge algorithm: bulk– absorption – recondition – float – storage – refresh: The Phoenix Smart Charger features our well-known ‘adaptive’ battery management system that can be preset to suit different types of batteries. The ‘adaptive’ feature will automatically optimize the charging process relative to the way the battery is being used.
• The right amount of charge: variable absorption time: When only shallow discharges occur (a yacht connected to shore power for example) the absorption time is kept short in order to prevent overcharging of the battery. After a deep discharge, the absorption time is automatically increased to make sure that the battery will be fully charged.
• Preventing damage due to excessive gassing: the BatterySafe mode: If in order to quickly charge a battery, a high charge current in combination with a high absorption voltage has been chosen, the charger will prevent damage due to excessive gassing by automatically limiting the rate of voltage increase once the gassing voltage has been reached.
• Less maintenance and aging when the battery is not in use: the Storage Mode: The Storage Mode kicks in whenever the battery has not been subjected to discharge for 24 hours. In the Storage Mode, float voltage is reduced to 2,2 V/cell (13,2 V for a 12 V battery) to minimize gassing and corrosion of the positive plates. Once a week the voltage is raised back to the absorption level to ‘equalize’ the battery. This feature prevents stratification of the electrolyte and sulphation, a major cause of early battery failure.
• Also charges Li-ion (LiFePO4) batteries: Charger on-off control can be implemented by connecting a relay or open collector optocoupler output from a Li-ion BMS to the remote on-off port. Alternatively, full control of voltage and current can be achieved with Bluetooth.
• Fully programmable charge algorithm: The charge algorithm can be programmed with help of Bluetooth or the VE.Direct interface. Three preprogrammed algorithms can be selected with the mode button.
• Optional external battery voltage and temperature sensing via Bluetooth: A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more Phoenix Smart IP43 Chargers.
• Remote on-off: The remote on/off consists of two terminals: Remote H and Remote L. A remote on/off switch or relay contact can be connected between H and L. Alternatively, terminal H can be pulled high, or terminal L can be pulled low.
• VE.Direct interface: For a wired data connection to a Color Control panel, PC, or other devices.
• Programmable relay: Can be programmed using the VE.Direct interface or a Bluetooth-enabled device to trip on an alarm or other events.
• Synchronized charging: Pairing two or more Phoenix Smart IP43 Chargers in a VE.Smart Network, enables synchronized charging. This improves the charge efficiency and battery life.

Specifications:

• Charger Input - Voltage: 120/240v
• Charger Output - Amps: 25a
• Charger Output Voltage: 24v
• Charging Banks: 3
• Portable: No
• Box Dimensions: 6"H x 10"W x 11"L WT: 7 lbs
• UPC: 8719076053552

Skylla - 24/100 TG Charger - 230V

One full rated output and one (1) 4 Amp output.  Charge voltage can be precisely adjusted to suit any battery system.

The input for the charger is 230V at 50/60HZ.  Charge voltage can be measured directly on the battery terminals in order to compensate for voltage loss due to cable resistance.

An external sensor allows to measure battery temperature and compensate charge voltage accordingly.

Features:

• Perfect chargers for any type of battery - Charge voltage can be precisely adjusted to suit any sealed or unsealed battery system.  In particular, sealed maintenance-free batteries must be charged correctly in order to ensure long service life.  Overvoltage will result in excessive gassing and venting of a sealed battery.  The battery will dry out and fail.
• Suitable for AC and DC supply (AC-DC and DC-DC operation)
• Every TG Charger has a microprocessor, which accurately controls the charging in three steps
• Use of TG Chargers as power supply - As a result of the perfectly stabilized output voltage, a TG Charger can be used as a power supply if batteries or large buffer capacitors are not available.
• Manufactured with a battery temperature sensor.  When connected, charge voltage will automatically decrease with increasing battery temperature.
• In order to compensate for voltage loss due to cable resistance, TG Chargers are provided with a voltage sensor so that the battery always receives the correct charge voltage

Technical Specifications:

•  Input Voltage - 230V AC
• Input Voltage Range - 185 to 264V AC
• Input Voltage Range - 180 to 400V DC
• Battery Capacity - 500 to 1000 Ah
•  Frequency - 45 to 65 Hz
• Battery Connection - M8 studs
• 230V AC Connection - Screw clamp (AWG 6)
• Dimensions (H x W x D) - 14.4" x 9.9" 10.1" (36.5 x 25 x 25.7 cm)
• Weight - 22 Lbs (10 kg)

In the Box:

• Charger
• Mounting brackets
• Temperature sensor with 4.9' (1.5 M) wire
• Instruction manual

*Sold as an Individual

ProTournament 500 Elite Series3 5-Bank On-Board Marine Battery Charger

The ProTournamentelite series3 has been taken to the next level of design and performance, providing a competitive edge that will put you on the water first with power to last. With true rated output amperage and models up to 50 amps with Distributed-On-Demand™ charging Technology, ProTournament delivers the fastest charge times in its class. Designed to innovate and boasting 3 distinct industry 1st patent pending features.

Features:

• 50 Amp/Five Bank
• IP 67 Sealed Waterproof Design
• Line of Sight, Charge Status AC Glow Plug
• Selectable Turbo Charge Mode
• Forced Power Flow Cooling
• 4 Digitally Selectable Charge Profiles
• Dual Mode Battery Status Monitor
• Distributed-On-Demand Technology™

Specifications:

• Charger Input - Voltage: 120v
• Charger Output - Amps: 50a
• Charger Output Voltage: 12/24/36/48v+1
• Charging Banks: 5
• Portable: No
• Box Dimensions: 9"H x 11"W x 18"L WT: 19.15 lbs
• UPC: 031669535053

XPLORE Battery Charger - 12V - 120 Amp - 6-Bank

The XPLORE 120/12 battery charger is the largest and most powerful charger on the market today. The universal, auto-ranging AC input and 120 amps of output current ensure ultra-fast and reliable worldwide charging. With up to six output banks of simultaneous charging combined with the ability to charge two battery banks with differing chemistries, the XPLORE 120/12 eliminates the need to have separate single-chemistry chargers and minimizes installation and wiring costs for your house bank and engine bank.

It is also equipped with an easy-to-read front panel LED display for basic configuration and status information. Advanced monitoring and configuration are enabled by NMEA 2000 protocol or Xantrex app using the Xantrex BLE module.

Performance Features:

• 6 Battery Banks and Dual-Chemistry Charging
• Xantrex Lithium and Custom Battery Charging
• NMEA 2000 Connectivity
• Xantrex App Connectivity
• Auto-ranging universal input voltage (80-265 Vac, 45-65 Hz)
• Power Share: automatically reduces charging output to prevent nuisance tripping of the AC input breaker.
• Quiet Mode: when enabled, the internal fan is turned off and the charger operates at a reduced output when quietness is needed.
• Storage Mode: automatically refreshes your batteries once every several days of non-use to ensure optimal battery condition.
• Dead Battery Charging: the ability to charge a battery as low as 0V back to full-charge

Protection Features:

• Reverse battery polarity protection
• Drip-proof design
• Over and under-temperature protection
• DC over-voltage protection
• Battery overcharging protection

ChargeMaster Plus 12/35-3 Battery Charger

Make the most of your batteries with the ChargeMaster series, plugging in and charging anywhere in the world. Mastervolt’s ChargeMaster guarantees fast and complete charging of your batteries no matter where you are. Thanks to Mastervolt’s innovative 3-step+ charging process, batteries also perform better and last longer.

All ChargeMasters can be easily connected to a MasterBus network with only one cable and one connection (with the exception of the ChargeMaster 12/10, ChargeMaster 12/15-2, and ChargeMaster 24/6). What’s more, you have the option for central, local, or remote monitoring, configuration, and control of your system.

Clear Display

A clearly lit display on the ChargeMaster provides all essential information: charge current, charge voltage, charge phase, and battery content measurement and/or battery condition measurement as a percentage of available Ah capacity. The display also provides an indication of MasterBus communication. Three buttons adjacent to the read-out panel allow for easy operating of the entire system.

The ChargeMaster is available in various models to guarantee you the ideal battery charger for any situation and demand.

Features:

• For recreational and semi-professional use.
• Suitable for any type of battery, including Lithium-Ion batteries.
• 3-Step+ charging technology for fast and complete charging also charges depleted batteries.
• Memory function prevents overcharging in case of unreliable mains.
• Safe and complete charging due to standard safety features.
• Charging capacity up to 1000 Ah battery banks.
• Easy to connect and quick to install.
• Can charge multiple battery banks simultaneously.
• Built-in system functionality (MasterBus) in combination with other Mastervolt products.
• Clear control panel (with the exception of the ChargeMaster 12/10, ChargeMaster 12/15-2, and ChargeMaster 24/6).
• Supplies your system without a battery.

Charging your batteries with every voltage

The Mastervolt ChargeMaster supplies a maximum capacity wherever you are via auto-ranging. Auto-ranging ensures perfect fully automatic operation anywhere in the world, regardless of the available mains voltage (90-265 V AC, 50 or 60 Hz). The 3-step+ charging technology guarantees fast and complete charging, while the cos phi 1-regulation gets the most out of limited generator capacity.

Robust Connections

Solid metal-to-metal connectors equipped with strain relief prevent corrosion and overheating.

Charging multiple battery banks

The ChargeMaster series has three equal charge outputs. Those of the smaller ChargeMaster models are pre-installed with two meters of cable for a plug & play solution, while the heavier models have one full output (for example for your service battery) and two outputs of 10 A, ideal for your starter batteries.

DC Power Supply

Even if the batteries are not connected, Mastervolt ChargeMaster battery chargers can provide a constant DC output allowing you to turn on lights or keep the fridge cold.

Specifications:

• Nominal output voltage: 12V
• Total charge current: 35 A at 14.4 V
• Number of battery outlets: 3
• Charge current second output: 35 A
• Charge current third output: 35 A
• Battery bank size: 70-350 Ah
• Nominal input voltage: 120/230 V (90-265 V), 50/60 Hz
• AC connection: Connector strips
• Power supply mode: Yes
• Galvanic isolation: Yes
• Display/read-out: LED display

Specifications:

• Charger Input - Voltage: 120/230v
• Charger Output - Amps: 35a
• Charger Output Voltage: 12v
• Charging Banks: 3
• Portable: No
• Box Dimensions: 6"H x 12"W x 15"L WT: 9.2 lbs
• UPC: 816882022876
