XKA Stainless Steel Trim Tab Kit with MLC-1 Control - 9 x 12

The Lectrotab stainless steel trim tab design provides unmatched strength and reliability.  All stainless steel tabs are fabricated with a continuous rolled and pinned hinge.  This design eliminates the need for welding.

Combined with a precision-engineered actuator, this kit is built to combine quiet operation with a non-hydraulic, maintenance free design.  The unit is corrosion free, ensures very accurate tab positioning, provides maximum lift force, and is totally self-contained for easy installation.  The actuator assembly is packaged in a non-metallic permanently sealed housing.  No components need to be installed inside the boat.

Most importantly, unlike hydraulic trim tabs, there is no oil to leak out.  The actuator incorporates either a standard or low profile transom mounting bracket.

The Lectrotab MLC-1 is a microprocessor based trim tab control that can move both tabs simultaneously at the touch of a single button.  It includes LED tab position indicators which will automatically dim in darkness and brighten in sunlight.

Features:

• Continuous rolled and pinned hinge provides added strength and eliminates the need for welding
• Upper ram seal location cannot be damaged due to fouled ram or barnacle growth
• Utilizes internal pressure equalization system
• Internal brake system prevents unwanted tab movement when under way or backing down
• Quiet operation
• Actuators are fully load tested to push 1000 lbs of force
• Non-metallic external structure which cannot corrode and will not deteriorate in the sun or under water

Technical Specifications:

• Trim Tab Size (L x W) - 9" x 12" (23 x 30 cm)
• Boat Length - 16' to 25' (5 to 7.5 M)
• Trim Tab Material - 12 gauge, 304 Stainless Steel
• Actuator DC Voltage - 12 V
• Actuator Stroke Length - 2.25" (57 mm)
• Actuator Cable Length  - 23' (7 M)
• Actuator Vertical Height - 11.875" (302 mm)
• Control Dimensions (W x H) - 3.15" x 3.07" (80 x 77 mm)
• Control Mounting Hole Cutout - 2" (50 mm)
• Control Operating Voltage - 12 or 24 V

In the Box:

• One (1) Manual Leveling Control
• Two (2) Stainless Steel tabs
• Two (2) actuators w/23' (7 M) cables
• Instruction Manual

*Sold as a Kit

Specifications:

• Actuator Type: Electro-Mechanical
• Construction: Stainless Steel
• Box Dimensions: 4"H x 5"W x 6"L WT: 17.3 lbs

BOLT 12x16 Heavy Duty Trim Tab System

Designed for rougher conditions and higher speeds, the BOLT1216HD (12” span x 16 chord”) heavy-duty electric trim tab system features an adjustable upper hinge actuator and requires less than 10.25” of vertical transom height. The high-performance laser-cut, tapered trim tabs are manufactured with extremely durable 12-gauge, electro-polished stainless steel, featuring a full-profile backing plate, and up-fins for added strength.

Control sold separately

Specifications:

• Construction: Stainless Steel
• Actuator Type: Electro-Mechanical
• Box Dimensions: 6"H x 20"W x 32"L WT: 35.1 lbs
• UPC: 666285600344

Dealer Service Kit

Exclusively offered to stocking dealers and repair yards, Bennett’s Dealer Service Kit is an affordable way to acquire the most common Bennett trim tab system replacement parts.

What's Included?

• (QTY / 1) BOLTBLTADJ – BOLT Electric System (Not Including Tabs)
• (QTY / 1) BRC4000 – Rocker Switch for Electric Systems
• (QTY / 1) ES2000 – Rocker Switch for Hydraulic Systems
• (QTY / 2) A1101CPEIC – Hydraulic Actuator with Sensor
• (QTY / 2) A1200SCPEIC – Short Hydraulic Actuator with Sensor
• (QTY / 1) V351HPU1D – Hydraulic Power Unit 12V w/Deutsch Connector
• (QTY / 1) H1170A Hardware Kit A
• (QTY / 1) H1170B Hardware Kit B
• (QTY / 2) T112520 20′ Hydraulic Tubing
• (QTY / 2) H1179 Mounting Bracket for HPU
• (QTY / 2) A1114 Lower Hinge with Hinge Pin
• (QTY / 1) VP1135G Solenoid Valve (G)
• (QTY / 1) VP1135R Solenoid Valve (R)
• (QTY / 2) T1127 Nut with Ferrule

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Fuel Flow Sensor 8-10 LPM/2.1-18.5 GPM

When fluid passes through the sensor, the rotors turn. Magnets which are located in the rotors will pass across sensors in the sensor circuit board. Pulses from these sensors are transmitted to the FFM100 which performs flow rate calculations based on the received pulses.

Specifications:

• Construction: Housing Material Aluminum

• Port Size: 3/4" NPT Female

• Maximum Viscosity: 1000 cPs

• Strainer Size: 60 Mesh (If not already installed after fuel filter)

WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.

Fuel Flow Sensor f/FFM100 Fuel Flow Monitor

Flow range: 48 to 396 GPH, 180 to 1500 LPH

WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.

Yamaha 90-115 Zero Torque Feedback Tiller

The four stroke outboard engines are generating high torque loads which can make tiller steered boats difficult to steer. The Uflex® ZTF Tiller systems eliminate propeller torque at the tiller handle when the driver is not actively changing direction.

Using a hydraulic valve, the propeller torque is locked from reaching the tiller handle unless the driver pushes or pulls on the end of the handle, at which point the valve opens and allows for active steering movements.

Now you can drive your tiller steered boat in comfort, saving your energy for reeling in fish rather than effort to just get to your favorite fishing spot.

Zeus A225OB-12V High Output Outboard Alternator Engineered Kit

Kit includes everything needed for Verado applications: alternator, alternator positive fuse link wire, alternator ground wire, battery sense wire, and OEM replacement alternator belt.

The ARCO Zeus A225ob-12V is a 225-amp, 3,500-watt high-output outboard alternator delivering 2 to 3x faster charge times compared to OEM units. It is part of the ARCO Zeus High Energy product family, engineered for boaters who need a complete onboard power upgrade, not just a component swap.

Features:

• 225 amps and 3,500 watts of charging capability with 2 to 3x faster charge times vs OEM units
• Engineered to help recharge large lithium banks at significantly faster rates than typical OEM alternators
• Built to support stabilizers, inverters, air conditioning, refrigeration, trolling motors, water and ice makers, and premium audio
• Batteries continue charging even at low engine speeds, including idle, so power is available when and where you need it
• Enables efficient charging without a dedicated engine or generator runtime

S5-AL Suspension Base - Black

The Shockwave S5-AL suspension base (formerly the S5 Sentinel) provides comfort and safety to boaters, offering them an experience they’ve never had before. It offers a smoother, safer, and more comfortable ride, protecting occupants from the shock of wave impact. Recreational boaters can stay out longer and travel farther with less fatigue. Made from anodized A360 cast aluminum that has been powder-coated and fitted with 316 stainless steel hardware, the S5-AL suspension base utilizes a four-link forward action suspension design.

Fitted with a FOX Rhythm air-sprung shock with adjustable rebound, suspension travel is 4-inch vertical and 1.5-inch forward, mitigating deceleration associated with wave impact.

A shock pump with a pressure gauge is included with your purchase at no extra cost.

Features:

• Designed and manufactured in Canada
• Custom-tuned and valved marine FOX Rhythm air spring and shock with adjustable rebound
• Surge protection: Suspension travel is 4-inch vertical and 1.5-inch forward, mitigating deceleration associated with wave impacts
• 4-Link Forward Action
• Anodized A360 Cast Aluminum, 316 SS Hardware, Powder Coated
• Minimal parts count and simple construction
• Easy to mount and adapt to the current seating

Vessel Application:

The S5-AL suspension base is most often found on fishing boats, coastal cruisers, ski/wake boats, guide boats, fisheries boats, whale watching boats, crew boats and yacht tenders. Due to its universal design, the S5-AL can be fitted to almost any boat and any seat.
